NVIDIA GeForce 940MX
GeForce 940MX to popularna w laptopach karta grafiki oparta na architekturze Maxwell, która pojawiła się w I połowie 2016 roku. Jest to układ wydajniejszy od układów zintegrowanych z procesorów Intela, ale dużo słabszy od kart grafiki stosowanych w laptopach do gier. Ma 64-bitową szynę danych. Występuje w wersjach z pamięcią VRAM DDR3 i GDDR5. Wersja z pamięcią GDDR5 jest o ponad 1/3 wydajniejsza.
GeForce 900M Rodzina Nazwa robocza N16S-GTR-B/S Architektura Maxwell Potoki 384 - ZJC TMUs 42 ROPs 16 Zegar rdzenia 1122 - 1242 (Boost) MHz Zegar pamięci 4000 effective = 1253 MHz Magistrala 64 bit Typ pamięci DDR3, GDDR5 Maks. pamięci 4 GB Pamięć współdzielona nie Memory Bandwidth 40.1 GB/s API DirectX 12 (FL 11_0), Shader 5.0, OpenGL 4.5 Pobór prądu 15-25 W Liczba tranzystorów 1.9 Billion Technologia 28 nm PCIe 3.0 Technologie GPU Boost 2.0, Optimus, PhysX, CUDA, GeForce Experience, GameWorks Wielkość laptopa średni Data premiery 10.03.2016 Witryna producenta http://www.geforce.com/hardware/notebook...
Testy Performance Rating - 3DMark 11 + Fire Strike + Time Spy
3.9 pt (4%)
...
...
3DMark - 3DMark Time Spy Score
min: 514 avg: 649 median: 710 (2%) max: 737 Points
...
Intel Iris Plus Graphics 655 -2%
Intel UHD Graphics Xe 750 32EUs (Rocket Lake) 14%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 24%
AMD Radeon RX Vega 5 27%
...
AMD Radeon RX 6850M XT 1692%
3DMark - 3DMark Time Spy Graphics
min: 456 avg: 577 median: 626 (2%) max: 647 Points
...
Intel Iris Plus Graphics 655 -2%
Intel UHD Graphics Xe 750 32EUs (Rocket Lake) 11%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 20%
AMD Radeon RX Vega 5 27%
...
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 110748 avg: 147080 median: 147706 (17%) max: 178806 Points
...
AMD Radeon RX Vega 5 -13%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -5%
Intel Iris Plus Graphics 655 -3%
Intel Iris Xe Graphics G7 80EUs 5%
AMD Radeon RX Vega 11 9%
Intel Iris Xe MAX Graphics 21%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 21%
...
3DMark - 3DMark Ice Storm Extreme Graphics
min: 26424 avg: 44072 median: 43341 (6%) max: 67037 Points
...
NVIDIA Quadro M1200 -4%
Intel UHD Graphics 770 5%
...
NVIDIA GeForce RTX 3080 Laptop GPU 842%
3DMark - 3DMark Cloud Gate Score
min: 5606 avg: 7905 median: 7674 (8%) max: 11839 Points
...
Intel HD Graphics P630 5%
...
AMD Radeon RX 6500M 1071%
3DMark - 3DMark Cloud Gate Graphics
min: 8165 avg: 11087 median: 11513 (4%) max: 14485 Points
...
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -9%
...
AMD Radeon RX 6850M XT 1502%
3DMark - 3DMark Fire Strike Standard Score
min: 1365 avg: 1773 median: 1834 (3%) max: 2256 Points
...
Intel Iris Plus Graphics 655 -5%
Intel UHD Graphics Xe G4 48EUs 7%
...
AMD Radeon RX 6850M XT 1451%
3DMark - 3DMark Fire Strike Standard Graphics
min: 1540 avg: 1955 median: 1996 (3%) max: 2403 Points
...
Intel UHD Graphics Xe G4 48EUs 10%
...
3DMark - 3DMark Ice Storm Graphics
min: 21217 avg: 52400 median: 48564 (6%) max: 84989 Points
...
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 4%
...
AMD Radeon RX 6800S 897%
3DMark 11 - 3DM11 Performance Score
min: 2205 avg: 2731 median: 2660.5 (4%) max: 3428 Points
...
Intel Iris Plus Graphics 655 6%
...
AMD Radeon RX 6850M XT 1045%
3DMark 11 - 3DM11 Performance GPU
min: 2171 avg: 2582 median: 2556 (2%) max: 3164 Points
...
Intel Iris Plus Graphics 655 4%
...
AMD Radeon RX 6850M XT 1530%
3DMark Vantage + 3DMark Vantage - 3DM Vant. Perf. total
min: 7479 avg: 8610 median: 8549 (2%) max: 9862 Points
...
...
NVIDIA GeForce RTX 3080 Ti Laptop GPU 1001%
3DM Vant. Perf. GPU no PhysX + 3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 6797 avg: 7691 median: 7268 (4%) max: 9432 Points
...
...
NVIDIA GeForce RTX 3080 Ti Laptop GPU 1232%
3DMark 2001SE - 3DMark 2001 - Standard
28793 Points (30%)
...
...
3DMark 03 - 3DMark 03 - Standard
min: 26745 avg: 28036 median: 28408 (15%) max: 28956 Points
...
...
3DMark 05 - 3DMark 05 - Standard
min: 19024 avg: 20861 median: 21184 (23%) max: 22050 Points
...
...
NVIDIA GeForce RTX 3060 Laptop GPU 134%
3DMark 06 3DMark 06 - Standard 1280x1024 +
min: 10351 avg: 13093 median: 12843 (18%) max: 15623 Points
...
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -2%
...
NVIDIA GeForce RTX 3080 Ti Laptop GPU 336%
Unigine Valley 1.0 - Unigine Valley 1.0 DX
min: 6.4 avg: 6.7 median: 6.7 (2%) max: 6.9 fps
...
AMD Radeon RX Vega 5 10%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 10%
AMD Radeon 540X 40%
...
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
min: 23.6 avg: 25.2 median: 25.2 (8%) max: 26.8 fps
...
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 1%
AMD Radeon RX Vega 5 4%
...
Unigine Heaven 3.0 - Unigine Heaven 3.0 OpenGL
min: 18.1 avg: 22 median: 22 (10%) max: 25.9 fps
...
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 4%
AMD Radeon RX Vega 5 12%
AMD Radeon 540X 13%
NVIDIA Quadro M1200 31%
...
Unigine Heaven 2.1 - Heaven 2.1 high
40.2 fps (8%)
Model CPU GPU RAM Wartość Acer Aspire E5-774G-78NA 6500U GeForce 940MX 861 / 1253 MHz 2 GB 8 GB 40.2
...
AMD Radeon RX Vega 6 (Ryzen 4000/5000) -8%
AMD Radeon 540X 3%
AMD Radeon RX Vega 7 11%
...
SPECviewperf 11 + SPECviewperf 11 - specvp11 snx-01
min: 5.52 avg: 5.9 median: 5.9 (4%) max: 6.21 fps
...
...
specvp11 tcvis-02 + SPECviewperf 11 - specvp11 tcvis-02
min: 1.33 avg: 1.5 median: 1.5 (3%) max: 1.75 fps
...
...
specvp11 sw-02 + SPECviewperf 11 - specvp11 sw-02
min: 10.59 avg: 12.2 median: 12.2 (15%) max: 13.8 fps
...
...
specvp11 proe-05 + SPECviewperf 11 - specvp11 proe-05
min: 2.48 avg: 3.1 median: 3.1 (13%) max: 3.77 fps
...
...
NVIDIA Quadro M1200 603%
specvp11 maya-03 + SPECviewperf 11 - specvp11 maya-03
min: 7.81 avg: 9.4 median: 9.4 (7%) max: 10.94 fps
...
NVIDIA NVS 5400M -5%
...
specvp11 lightwave-01 + SPECviewperf 11 - specvp11 lightwave-01
min: 18.63 avg: 19.7 median: 19.7 (21%) max: 20.8 fps
...
...
specvp11 ensight-04 + SPECviewperf 11 - specvp11 ensight-04
min: 19.12 avg: 21.1 median: 21.1 (10%) max: 23 fps
...
...
specvp11 catia-03 + SPECviewperf 11 - specvp11 catia-03
min: 10.7 avg: 12.3 median: 12.3 (15%) max: 13.92 fps
...
...
SPECviewperf 12 + SPECviewperf 12 - specvp12 sw-03
16.4 fps (7%)
Model CPU GPU RAM Wartość Lenovo ThinkPad T460p-20FXS05500 6700HQ GeForce 940MX 1176 / 1000 MHz 2 GB 8 GB 16.4
...
NVIDIA GeForce MX250 2%
...
specvp12 snx-02 + SPECviewperf 12 - specvp12 snx-02
2.2 fps (1%)
Model CPU GPU RAM Wartość Lenovo ThinkPad T460p-20FXS05500 6700HQ GeForce 940MX 1176 / 1000 MHz 2 GB 8 GB 2.22
Intel Iris Xe MAX Graphics -56%
...
NVIDIA GeForce MX250 -5%
...
specvp12 showcase-01 + SPECviewperf 12 - specvp12 showcase-01
6.9 fps (2%)
Model CPU GPU RAM Wartość Lenovo ThinkPad T460p-20FXS05500 6700HQ GeForce 940MX 1176 / 1000 MHz 2 GB 8 GB 6.91
...
...
AMD Radeon RX 6800M 2056%
specvp12 mediacal-01 + SPECviewperf 12 - specvp12 mediacal-01
6.3 fps (2%)
Model CPU GPU RAM Wartość Lenovo ThinkPad T460p-20FXS05500 6700HQ GeForce 940MX 1176 / 1000 MHz 2 GB 8 GB 6.28
...
...
specvp12 maya-04 + SPECviewperf 12 - specvp12 maya-04
13.7 fps (4%)
Model CPU GPU RAM Wartość Lenovo ThinkPad T460p-20FXS05500 6700HQ GeForce 940MX 1176 / 1000 MHz 2 GB 8 GB 13.68
...
...
specvp12 energy-01 + SPECviewperf 12 - specvp12 energy-01
0.3 fps (0%)
Model CPU GPU RAM Wartość Lenovo ThinkPad T460p-20FXS05500 6700HQ GeForce 940MX 1176 / 1000 MHz 2 GB 8 GB 0.32
...
Intel Iris Xe Graphics G7 96EUs 34%
...
specvp12 creo-01 + SPECviewperf 12 - specvp12 creo-01
8 fps (4%)
Model CPU GPU RAM Wartość Lenovo ThinkPad T460p-20FXS05500 6700HQ GeForce 940MX 1176 / 1000 MHz 2 GB 8 GB 7.97
Intel Iris Xe Graphics G7 96EUs 5%
Intel Iris Xe MAX Graphics 29%
NVIDIA GeForce MX250 33%
...
specvp12 catia-04 + SPECviewperf 12 - specvp12 catia-04
10.5 fps (3%)
Model CPU GPU RAM Wartość Lenovo ThinkPad T460p-20FXS05500 6700HQ GeForce 940MX 1176 / 1000 MHz 2 GB 8 GB 10.47
...
NVIDIA GeForce MX250 -13%
...
Cinebench R10 Cinebench R10 Shading (32bit) + Cinebench R10 - Cinebench R10 Shading (32bit)
min: 3154 avg: 5792 median: 6321.5 (4%) max: 8276 pkt.
...
NVIDIA Quadro P1000 -1%
NVIDIA GeForce MX230 2%
...
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit + Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 38.34 avg: 51.9 median: 49.6 (18%) max: 70 fps
...
Intel Iris Plus Graphics 655 0%
...
NVIDIA RTX A2000 Laptop GPU 241%
Cinebench R15 + Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 38.08 avg: 63.8 median: 64.5 (17%) max: 81.6 fps
...
AMD Radeon RX Vega 6 (Ryzen 4000/5000) -9%
AMD Radeon RX Vega 5 -2%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -2%
Intel UHD Graphics Xe G4 48EUs 2%
Intel Iris Plus Graphics 655 4%
AMD Radeon 540X 4%
AMD Radeon RX Vega 7 6%
...
NVIDIA RTX A1000 Laptop GPU 361%
Cinebench R15 OpenGL Ref. Match 64 Bit + Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
min: 2.34 avg: 97 median: 99.6 (100%) max: 99.6 %
...
Intel UHD Graphics 610 1%
Intel Iris Xe Graphics G7 96EUs 1%
Intel Arc A730M 1%
...
NVIDIA GeForce MX250 3%
GFXBench (DX / GLBenchmark) 2.7 + GFXBench (DX / GLBenchmark) 2.7 - GFXBench 2.7 T-Rex HD Onscreen C24Z16
min: 56.2 avg: 58.1 median: 58.1 (2%) max: 59.9 fps
...
Intel UHD Graphics Xe G4 48EUs 0%
NVIDIA T600 Laptop GPU 1%
Qualcomm Adreno 680 1%
Qualcomm Adreno 685 2%
...
GFXBench T-Rex HD Offscreen C24Z16 + GFXBench (DX / GLBenchmark) 2.7 - GFXBench T-Rex HD Offscreen C24Z16
min: 130 avg: 141.2 median: 131.1 (1%) max: 162.5 fps
...
Qualcomm Adreno 680 -1%
AMD Radeon RX Vega 5 17%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 17%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 18%
Qualcomm Adreno 685 19%
...
NVIDIA GeForce RTX 3080 Ti Laptop GPU 1574%
GFXBench 3.0 - GFXBench 3.0 Manhattan
min: 41.4 avg: 48.3 median: 48.3 (13%) max: 55.2 fps
...
Intel UHD Graphics 770 -5%
Intel UHD Graphics (Jasper Lake 32 EU) -3%
...
GFXBench 3.0 - GFXBench 3.0 Manhattan Offscreen
min: 67.5 avg: 73.5 median: 69.3 (5%) max: 83.7 fps
...
AMD Radeon RX Vega 5 -9%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 5%
AMD Radeon 540X 5%
AMD Radeon RX Vega 7 23%
NVIDIA GeForce MX230 24%
...
Apple M1 Max 32-Core GPU 1569%
GFXBench - GFXBench Car Chase Onscreen
min: 27 avg: 32.3 median: 32.3 (1%) max: 37.6 fps
...
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -13%
NVIDIA T600 Laptop GPU 6%
NVIDIA GeForce MX230 18%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 20%
...
NVIDIA GeForce RTX 3070 Laptop GPU 10872%
GFXBench - GFXBench Car Chase Offscreen
min: 37.5 avg: 41.8 median: 41.8 (0%) max: 46 fps
...
AMD Radeon RX Vega 6 (Ryzen 4000/5000) -6%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -1%
NVIDIA GeForce MX230 8%
AMD Radeon 540X 19%
AMD Radeon RX Vega 7 30%
...
NVIDIA GeForce RTX 3070 Laptop GPU 57759%
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
min: 366 avg: 394 median: 394 (2%) max: 422 Samples/s
...
AMD Radeon RX Vega 5 -4%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) -3%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 0%
NVIDIA GeForce MX350 16%
AMD Radeon RX Vega 7 17%
...
NVIDIA GeForce GTX 1650 Ti Mobile 2380%
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
min: 611 avg: 799 median: 799 (1%) max: 987 Samples/s
...
AMD Radeon RX Vega 6 (Ryzen 4000/5000) -6%
AMD Radeon 680M 0%
...
AMD Radeon RX 6700M 1463%
ComputeMark v2.1 - ComputeMark v2.1 Result
min: 1870 avg: 1936 median: 1928 (2%) max: 2016 pkt.
...
Intel Iris Plus Graphics 655 -5%
Intel UHD Graphics Xe G4 48EUs -4%
Qualcomm Adreno 680 -2%
NVIDIA GeForce MX230 4%
AMD Radeon RX Vega 5 10%
Qualcomm Adreno 685 18%
...
NVIDIA GeForce RTX 3080 Ti Laptop GPU 1487%
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
65.9 Watt (9%)
...
NVIDIA GeForce MX450 -15%
Intel UHD Graphics Xe 750 32EUs (Rocket Lake) -9%
Intel Arc A350M -8%
NVIDIA RTX A1000 Laptop GPU -3%
NVIDIA GeForce GTX 1650 Ti Max-Q 1%
Intel Arc A370M 3%
NVIDIA GeForce GTX 1650 Ti Mobile 10%
...
AMD Radeon RX 6850M XT 229%
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
45.5 Watt (6%)
Intel UHD Graphics (Jasper Lake 32 EU) -67%
...
NVIDIA GeForce MX250 -7%
AMD Radeon RX Vega 8 (Ryzen 4000/5000) -6%
NVIDIA T500 Laptop GPU -4%
NVIDIA GeForce MX350 8%
Intel Iris Xe MAX Graphics 9%
AMD Radeon 680M 13%
...
AMD Radeon RX 6850M XT 452%
Power Consumption - Witcher 3 Power Consumption *
min: 38.5 avg: 45.2 median: 46.2 (10%) max: 51.9 Watt
...
Intel Iris Xe Graphics G7 96EUs -12%
AMD Radeon RX Vega 8 (Ryzen 4000/5000) -6%
Intel Iris Plus Graphics 655 -4%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) -3%
NVIDIA T550 Laptop GPU -2%
NVIDIA GeForce MX250 10%
NVIDIA T500 Laptop GPU 10%
Intel Iris Xe MAX Graphics 12%
...
Power Consumption - Witcher 3 ultra Power Efficiency
min: 0.1767 avg: 0.2 median: 0.2 (26%) max: 0.2078 Points per Watt
...
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) -11%
Intel UHD Graphics (Jasper Lake 32 EU) -11%
NVIDIA Quadro M1200 -10%
Intel UHD Graphics (Jasper Lake 24 EU) 6%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 15%
NVIDIA GeForce MX330 18%
...
AMD Radeon RX 6800S 246%
Clock Speed - GPU Clock Witcher 3 ultra
888 MHz (44%)
Model CPU GPU RAM Wartość Huawei MateBook D 15, i7-7500U 940MX i7-7500U GeForce 940MX 1176 / 900 MHz 2 GB 8 GB 888
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -31%
Intel Iris Plus Graphics 655 12%
...
AMD Radeon 660M 114%
- Zakres wyników testów referencyjnych dla tej karty graficznej
- Średnia wartość wyników testów referencyjnych dla tej karty graficzne
* Smaller numbers mean a higher performance
Testy gier Zamieszczone niżej wyniki pochodzą z testów zrecenzowanych laptopów. Należy pamiętać, że osiągi poszczególnych konfiguracji zależą od zastosowanej pamięci własnej karty (VRAM), zegarów karty (mogą być różne), procesora, ustawień systemu, sterowników i wersji systemu operacyjnego. Tym samym uzyskane wyniki nie muszą być reprezentatywne dla wszystkich laptopów wyposażonych w daną kartę graficzną. By uzyskać szczegółowe informacje o wynikach testów, należy kliknąć na podaną wartość liczbową (fps, czyli kl/s).
...
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -46%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -7%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 10%
Intel UHD Graphics Xe G4 48EUs 15%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 25%
AMD Radeon RX Vega 5 26%
Intel Iris Xe Graphics G7 80EUs 29%
Apple M1 Pro 14-Core GPU 35%
NVIDIA GeForce MX250 59%
...
NVIDIA GeForce RTX 3080 Ti Laptop GPU 572%
Intel UHD Graphics 610 -67%
...
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -48%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 2%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 4%
AMD Radeon RX Vega 5 9%
Intel UHD Graphics Xe G4 48EUs 17%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 18%
Intel Iris Xe Graphics G7 80EUs 40%
...
NVIDIA GeForce RTX 3080 Ti Laptop GPU 1148%
Intel UHD Graphics 610 -69%
AMD Radeon RX Vega 5 -27%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) -3%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -3%
Intel UHD Graphics Xe G4 48EUs 14%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 19%
NVIDIA GeForce MX250 45%
Intel Iris Xe Graphics G7 80EUs 57%
NVIDIA GeForce MX330 59%
AMD Radeon RX Vega 7 61%
...
NVIDIA GeForce RTX 3080 Ti Laptop GPU 1391%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) -4%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -2%
Intel UHD Graphics Xe G4 48EUs 10%
NVIDIA GeForce MX250 43%
NVIDIA GeForce MX330 43%
Intel Iris Xe Graphics G7 80EUs 45%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 48%
NVIDIA GeForce MX350 80%
...
NVIDIA GeForce RTX 3080 Ti Laptop GPU 1634%
» Na wszystkich testowanych laptopach grywalna przy ustawieniach low.
...
Deutsch
English
Español
Français
Italiano
Nederlands
Português
Русский
Türkçe
Svenska
Chinese
Magyar
- Średnia wartość wyników testów referencyjnych dla tej karty graficzne
