Notebookcheck Logo

Intel Iris Pro Graphics 580

-

Gen. 9 Rodzina

Iris Pro Graphics P580 72 @ 0.35 - 1.1 GHzeDRAM + 64/128 bit
Iris Pro Graphics 580 72 @ 0.35 - 1.05 GHzeDRAM + 64/128 bit
Iris Graphics 550 48 @ 0.3 - 1.1 GHzeDRAM + 64/128 bit
Iris Graphics 540 48 @ 0.3 - 1.05 GHzeDRAM + 64/128 bit
HD Graphics 530 24 @ 0.35 - 1.15 GHz64/128 bit
HD Graphics 520 24 @ 0.3 - 1.05 GHz64/128 bit
HD Graphics 515 24 @ 0.3 - 1 GHz64/128 bit
UHD Graphics 610 12 @ 0.3 - 0.95 GHz64/128 bit
HD Graphics 610 12 @ 0.3 - 0.95 GHz64/128 bit
HD Graphics 510 12 @ 0.3 - 0.95 GHz64/128 bit
UHD Graphics 605 18 @ 0.3 - 0.75 GHz64/128 bit
HD Graphics 505 18 @ 0.3 - 0.75 GHz64/128 bit
UHD Graphics 600 12 @ 0.3 - 0.7 GHz64/128 bit
HD Graphics 500 12 @ 0.3 - 0.7 GHz64/128 bit
Nazwa roboczaSkylake GT4e
ArchitekturaGen. 9 Skylake
Potoki72 - ZJC
Zegar rdzenia350 - 1050 (Boost) MHz
MagistralaeDRAM + 64/128 bit
Typ pamięcieDRAM
Maks. pamięci128 MB
Pamięć współdzielonatak
APIDirectX 12_1, OpenGL 4.4
Technologia14 nm
TechnologieQuickSync
Data premiery24.01.2016
CPU in Iris Pro Graphics 580GPU Base SpeedGPU Boost / Turbo
Intel Core i7-6970HQ4 x 2800 MHz, 45 W350 MHz1050 MHz
Intel Core i7-6870HQ4 x 2700 MHz, 45 W350 MHz1000 MHz
Intel Core i7-6770HQ4 x 2600 MHz, 45 W350 MHz950 MHz
Intel Core i5-6350HQ4 x 2300 MHz, 45 W350 MHz900 MHz
min. - max.350 MHz900 - 1050 MHz

Testy

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.9 pt (3%)
3DMark - 3DMark Ice Storm Unlimited Graphics
184880 Points (21%)
3DMark - 3DMark Ice Storm Extreme Graphics
98218 Points (13%)
3DMark - 3DMark Cloud Gate Score
11346 Points (12%)
3DMark - 3DMark Cloud Gate Graphics
14594 Points (4%)
3DMark - 3DMark Fire Strike Standard Score
1836 Points (3%)
3DMark - 3DMark Fire Strike Standard Graphics
1903 Points (2%)
3DMark - 3DMark Ice Storm Graphics
149585 Points (18%)
3DMark 11 - 3DM11 Performance Score
3510 Points (5%)
3DMark 11 - 3DM11 Performance GPU
3220 Points (3%)
171.8 -95%
...
2965 -8%
2967 -8%
2973 -8%
2985 -7%
3022 -6%
3101 -4%
3106 -4%
3131 -3%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
3180 -1%
Intel Iris Pro Graphics 580
3220
3238 1%
3249 1%
3261 1%
Intel UHD Graphics Xe G4 48EUs
3288 2%
3310 3%
3313 3%
3314 3%
NVIDIA GeForce MX230
3392 5%
3392 5%
...
59943 1762%
max:
106023 3193%
0%
100%
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
11355 pkt. (8%)
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
63 fps (22%)
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 85.1     avg: 85.6     median: 85.6 (5%)     max: 86 fps
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
min: 97.8     avg: 97.9     median: 97.8 (98%)     max: 98 %
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
362 Samples/s (2%)
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
875 Samples/s (2%)
ComputeMark v2.1 - ComputeMark v2.1 Result
2308 pkt. (2%)
- Zakres wyników testów referencyjnych dla tej karty graficznej
- Średnia wartość wyników testów referencyjnych dla tej karty graficzne
* Smaller numbers mean a higher performance

Testy gier

Zamieszczone niżej wyniki pochodzą z testów zrecenzowanych laptopów. Należy pamiętać, że osiągi poszczególnych konfiguracji zależą od zastosowanej pamięci własnej karty (VRAM), zegarów karty (mogą być różne), procesora, ustawień systemu, sterowników i wersji systemu operacyjnego. Tym samym uzyskane wyniki nie muszą być reprezentatywne dla wszystkich laptopów wyposażonych w daną kartę graficzną. By uzyskać szczegółowe informacje o wynikach testów, należy kliknąć na podaną wartość liczbową (fps, czyli kl/s).

Overwatch

Overwatch

2016
low 1280x720
60.5  fps    + Porównaj
med. 1366x768
53.3  fps    + Porównaj
high 1920x1080
42.9  fps    + Porównaj
ultra 1920x1080
23.1  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
Additional Benchmarks
Medium (Render Scale 100 %) 2xAF FXAA 1920x1080
78.7
low 1024x768
30.2  fps    + Porównaj
med. 1366x768
18.2  fps    + Porównaj
high 1920x1080
12.2  fps    + Porównaj
ultra 1920x1080
8.9  fps    + Porównaj
» Niegrywalna na większości testowanych laptopów.
Fallout 4

Fallout 4

2015
low 1280x720
0 (!)  fps    + Porównaj
low 1024x768
59.9  fps    + Porównaj
med. 1366x768
58.6  fps    + Porównaj
high 1920x1080
23  fps    + Porównaj
ultra 1920x1080
14.9  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
low 1280x720
59.8  fps    + Porównaj
med. 1366x768
37.2  fps    + Porównaj
high 1920x1080
15.3  fps    + Porównaj
ultra 1920x1080
14  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
Thief

Thief

2014
low 1024x768
43.8  fps    + Porównaj
med. 1366x768
30.1  fps    + Porównaj
high 1366x768
25  fps    + Porównaj
ultra 1920x1080
12.4  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach low.
low 1024x768
63.7  fps    + Porównaj
med. 1366x768
50.8  fps    + Porównaj
high 1366x768
28.5  fps    + Porównaj
ultra 1920x1080
14.3  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
low 1280x720
101.3  fps    + Porównaj
med. 1366x768
57.9  fps    + Porównaj
high 1366x768
51  fps    + Porównaj
ultra 1920x1080
14.9  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
low 1024x768
380.6  fps    + Porównaj
med. 1366x768
127.1  fps    + Porównaj
high 1366x768
73.6  fps    + Porównaj
ultra 1920x1080
36.2  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach ultra.
low 1024x768
115.8  fps    + Porównaj
high 1366x768
38.7  fps    + Porównaj
ultra 1920x1080
16.7  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
low 1024x768
107.2  fps    + Porównaj
med. 1366x768
81.2  fps    + Porównaj
high 1366x768
37.3  fps    + Porównaj
ultra 1920x1080
8.8  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
lowmed.highultraQHD4K
Overwatch60.553.342.923.1
Doom
Rise of the Tomb Raider30.218.212.28.9
Fallout 4
Metal Gear Solid V59.958.62314.9
Dota 2 Reborn59.837.215.314
Batman: Arkham Knight
Thief43.830.12512.4
Metro: Last Light63.750.828.514.3
BioShock Infinite101.357.95114.9
StarCraft II: Heart of the Swarm380.6127.173.636.2
Guild Wars 2115.838.716.7
Sleeping Dogs107.281.237.38.8
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps

4
5
1
1
6
1
1
5
4
1
9
1







Więcej informacji w rankingu płynności w grach
