Intel UHD Graphics 770
UHD Graphics 770 to zintegrowana karta graficzna (IGP, GT1) w układach SoC Alder Lake i Raptor Lake, która oferuje 32 jednostki wykonawcze (EU) i taktowanie do 1,65 GHz (w zależności od modelu procesora).
Wydajność zależy od modelu procesora, z którym jest zintegrowany i używanej pamięci. Wydajność w grach, nawet na szybkich modelach, nadaje się tylko do mało wymagających gier w 720p i niskich ustawieniach detali. Bardziej wymagające gry, takie jak Cyberpunk 2077 czy Dying Light 2 (patrz benchmarki poniżej), nie działały dobrze w naszych testach.
GPU obsługuje do 4 wyświetlaczy z eDP 1.4b (5k120), DisplayPort 1.4a (8k60) i HDMI 2.1 (4k60).
SoC Alder Lake są produkowane w procesie technologicznym o nazwie "Intel 7" (ulepszony 10 nm w firmie Intel).
Gen. 12 / xG Rodzina UHD Graphics 770 32/ cores @ 0.3 - 1.55 GHz UHD Graphics 750
Nazwa robocza Alder Lake xG Architektura Alder Lake Potoki 32 / pikseli / wierzcholków TMUs 16 ROPs 8 Zegar rdzenia 300 - 1550 (Boost) MHz Pamięć współdzielona nie Pobór prądu 15 W Technologia 10 nm Data premiery 04.01.2022
CPU in UHD Graphics 770 GPU Base Speed GPU Boost / Turbo Intel Core i9-14900K 24 x 3200 MHz, 125 W 300 MHz 1650 MHz Intel Core i9-13900K 24 x 3000 MHz, 125 W 300 MHz 1650 MHz Intel Core i7-14700K 20 x 2500 MHz, 125 W 300 MHz 1600 MHz » show 27 more Intel Core i7-13700K 16 x 3400 MHz, 125 W 300 MHz 1600 MHz Intel Core i9-14900 24 x 2000 MHz, 65 W 300 MHz 1650 MHz Intel Core i9-13980HX 24 x 1600 MHz, 55 W ? MHz 1650 MHz Intel Core i9-13950HX 24 x 1600 MHz, 55 W ? MHz 1650 MHz Intel Core i9-12900K 16 x 3200 MHz, 125 W 300 MHz 1550 MHz Intel Core i5-14600K 14 x 3500 MHz, 125 W 300 MHz 1550 MHz Intel Core i5-13600K 14 x 3500 MHz, 125 W 300 MHz 1500 MHz Intel Core i7-14700HX 20 x 3900 MHz, 55 W ? MHz 1600 MHz Intel Core i7-13850HX 20 x 1500 MHz, 55 W ? MHz 1600 MHz Intel Core i9-12900 16 x 2400 MHz, 65 W 300 MHz 1550 MHz Intel Core i7-13700 16 x 2100 MHz, 65 W 300 MHz 1600 MHz Intel Core i9-12950HX 16 x 1700 MHz, 55 W ? MHz 1550 MHz Intel Core i9-12900HX 16 x 1700 MHz, 55 W ? MHz 1550 MHz Intel Core i7-14650HX 16 x 1600 MHz, 55 W ? MHz 1600 MHz Intel Core i7-13700HX 16 x 1500 MHz, 55 W ? MHz 1550 MHz Intel Core i7-12700K 12 x 2700 MHz, 125 W 300 MHz 1500 MHz Intel Core i5-14500 14 x 2600 MHz, 65 W 300 MHz 1550 MHz Intel Core i7-12850HX 16 x 1500 MHz, 55 W ? MHz 1450 MHz Intel Core i7-12800HX 16 x 1500 MHz, 55 W ? MHz 1450 MHz Intel Core i5-13500 14 x 2500 MHz, 65 W 300 MHz 1550 MHz Intel Core i7-12700 12 x 3300 MHz, 65 W 300 MHz 1500 MHz Intel Core i5-12600K 10 x 2800 MHz, 125 W 300 MHz 1450 MHz Intel Core i7-12650HX 14 x 1500 MHz, 55 W ? MHz 1450 MHz Intel Core i5-13600HX 14 x 1900 MHz, 55 W ? MHz 1500 MHz Intel Core i5-12600HX 12 x 1800 MHz, 55 W ? MHz 1350 MHz Intel Core i5-14500T 14 x 1700 MHz, 35 W 300 MHz 1550 MHz Intel Core i5-13500T 14 x 1600 MHz, 35 W 300 MHz 1550 MHz min. - max. 300 MHz 1350 - 1650 MHz
Testy Performance Rating - 3DMark 11 + Fire Strike + Time Spy
1.2 pt (4%)
...
AMD Radeon RX Vega 5
NVIDIA GeForce MX230
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
...
max:
3DMark - 3DMark Time Spy Score
min: 768 avg: 863 median: 856 (2%) max: 930 Points
...
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
AMD Radeon RX Vega 5
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
NVIDIA GeForce MX230
Intel UHD Graphics Xe G4 48EUs
Qualcomm Adreno 690
AMD Radeon 540X
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
...
max:
3DMark - 3DMark Time Spy Graphics
min: 666 avg: 744 median: 738 (2%) max: 798 Points
...
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
AMD Radeon RX Vega 5
NVIDIA GeForce MX230
Intel UHD Graphics Xe G4 48EUs
AMD Radeon 540X
Qualcomm Adreno 690
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
...
max:
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 116280 avg: 139293 median: 119185 (12%) max: 179804 Points
...
AMD Radeon RX Vega 5
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
Intel Iris Plus Graphics 655
AMD Radeon RX Vega 11
...
max:
NVIDIA GeForce RTX 3070 Ti
3DMark - 3DMark Ice Storm Extreme Graphics
min: 46258 avg: 54274 median: 52927 (7%) max: 61769 Points
...
Intel UHD Graphics Xe G4 48EUs
NVIDIA GeForce MX330
NVIDIA GeForce MX450
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
Intel Iris Xe Graphics G7 80EUs
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
...
max:
3DMark - 3DMark Cloud Gate Score
min: 14271 avg: 16270 median: 16618 (18%) max: 17404 Points
...
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
NVIDIA GeForce MX350
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
NVIDIA T500 Laptop GPU
Intel Iris Xe Graphics G7 80EUs
...
AMD Radeon RX 6800S
max:
3DMark - 3DMark Cloud Gate Graphics
min: 14455 avg: 16122 median: 16443 (4%) max: 16983 Points
...
Intel UHD Graphics Xe G4 48EUs
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
NVIDIA GeForce MX230
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
Qualcomm Adreno 690
AMD Radeon RX Vega 5
...
max:
3DMark - 3DMark Fire Strike Standard Score
min: 2163 avg: 2518 median: 2494.5 (4%) max: 2790 Points
...
NVIDIA GeForce MX230
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
AMD Radeon 540X
Qualcomm Adreno 690
...
max:
3DMark - 3DMark Fire Strike Standard Graphics
min: 2363 avg: 2664 median: 2655 (3%) max: 2900 Points
...
AMD Radeon RX Vega 5
NVIDIA GeForce MX230
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
AMD Radeon 540X
...
max:
3DMark - 3DMark Ice Storm Graphics
min: 58760 avg: 76751 median: 78188 (9%) max: 89577 Points
...
NVIDIA T600 Laptop GPU
AMD Radeon 610M
NVIDIA GeForce MX230
NVIDIA GeForce MX250
NVIDIA Quadro P1000
...
max:
3DMark - 3DMark Wild Life Unlimited
7086 Points (4%)
...
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
AMD Radeon RX Vega 7
Intel UHD Graphics Xe G4 48EUs
NVIDIA GeForce MX250
Intel Iris Xe Graphics G7 80EUs
AMD Radeon RX Vega 8 (Ryzen 4000/5000)
NVIDIA GeForce MX350
Intel Iris Xe Graphics G7 96EUs
NVIDIA GeForce MX450
Intel Iris Xe MAX Graphics
...
Apple M1 Max 32-Core GPU
max:
3DMark - 3DMark Wild Life Extreme Unlimited
1891 Points (2%)
...
Intel UHD Graphics (Jasper Lake 32 EU)
Intel UHD Graphics Xe 750 32EUs (Rocket Lake)
Intel UHD Graphics Xe G4 48EUs
AMD Radeon RX Vega 7
AMD Radeon RX Vega 8 (Ryzen 4000/5000)
Intel Iris Xe Graphics G7 80EUs
Qualcomm Adreno 690
Intel Iris Xe Graphics G7 96EUs
...
max:
3DMark - 3DMark Night Raid
12747 Points (12%)
...
Intel UHD Graphics Xe G4 48EUs
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
AMD Radeon RX Vega 11
AMD Radeon RX Vega 5
AMD Radeon 610M
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
AMD Radeon RX Vega 7
NVIDIA GeForce MX330
Intel Iris Xe Graphics G7 80EUs
NVIDIA GeForce MX350
AMD Radeon RX Vega 8 (Ryzen 4000/5000)
Intel Iris Xe Graphics G7 96EUs
Intel Iris Xe MAX Graphics
...
max:
3DMark - 3DMark Night Raid Graphics Score
12097 Points (5%)
...
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
AMD Radeon RX Vega 11
AMD Radeon 610M
AMD Radeon RX Vega 5
Intel UHD Graphics Xe G4 48EUs
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
AMD Radeon RX Vega 7
Intel Iris Xe Graphics G7 80EUs
AMD Radeon RX Vega 8 (Ryzen 4000/5000)
NVIDIA GeForce MX330
NVIDIA GeForce MX350
Intel Iris Xe Graphics G7 96EUs
Intel Iris Xe MAX Graphics
NVIDIA GeForce MX450
...
max:
3DMark 11 - 3DM11 Performance Score
min: 3665 avg: 3969 median: 3957 (5%) max: 4181 Points
...
NVIDIA GeForce MX230
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
AMD Radeon RX Vega 5
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
AMD Radeon 540X
...
max:
3DMark 11 - 3DM11 Performance GPU
min: 3268 avg: 3445 median: 3428 (3%) max: 3591 Points
...
Intel UHD Graphics Xe G4 48EUs
NVIDIA GeForce MX230
AMD Radeon RX Vega 5
...
max:
3DMark Vantage + 3DMark Vantage - 3DM Vant. Perf. total
min: 12664 avg: 14563 median: 14821 (4%) max: 15865 Points
...
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
...
max:
NVIDIA T600
3DM Vant. Perf. GPU no PhysX + 3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 10089 avg: 11562 median: 11740 (6%) max: 12456 Points
...
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
