Intel Iris Pro Graphics 5200

-
Producent | Intel |
Iris Rodzina | |
Nazwa robocza | Haswell GT3e |
Architektura | Gen. 7.5 Haswell |
Potoki | 40 - ZJC |
Zegar rdzenia | 200 - 1300 (Boost) MHz |
Magistrala | eDRAM + 64/128 bit |
Typ pamięci | eDRAM |
Maks. pamięci | 128 MB |
Pamięć współdzielona | tak |
DirectX | DirectX 11.1, Shader 5.0 |
Technologia | 22 nm |
Technologie | QuickSync |
Wielkość laptopa | średni |
Data premiery | 05.06.2013 |
Testy
Performance Rating - 3DMark 11 + Fire Strike + Time Spy
9.1 pt (10%)
...
NVIDIA GeForce MX330 -7%
AMD Radeon R7 512 Cores (Kaveri Desktop) -7%
Intel Iris Pro Graphics 5200
Intel Iris Xe Graphics G7 80EUs 2%
NVIDIA GeForce MX230 5%
...
AMD Radeon RX 6800 XT 939%
3DMark - 3DMark Ice Storm Unlimited Graphics
110085 Points (17%)
...
ARM Mali-G78 MP14 -12%
Qualcomm Adreno 640 -2%
Intel Iris Pro Graphics 5200
ARM Mali-G78 MP24 12%
...
NVIDIA GeForce RTX 3080 Laptop GPU 405%
3DMark - 3DMark Cloud Gate Score
min: 9027 avg: 9915 median: 9877 (13%) max: 10879 Points
...
Intel UHD Graphics Xe G4 48EUs -7%
Intel Iris Pro Graphics 5200
NVIDIA GeForce GTS 450 3%
NVIDIA GeForce MX230 5%
...
AMD Radeon RX 6800 XT 623%
3DMark - 3DMark Cloud Gate Graphics
min: 11338 avg: 11951 median: 11930 (6%) max: 12584 Points
...
ATI Radeon HD 4850 -6%
Intel Iris Pro Graphics 5200
NVIDIA GeForce GTS 450 4%
Intel UHD Graphics Xe 750 32EUs 5%
...
NVIDIA GeForce RTX 3090 1533%
3DMark - 3DMark Fire Strike Standard Score
min: 1281 avg: 1376 median: 1340 (3%) max: 1543 Points
...
AMD Radeon R7 384 Cores (Kaveri Desktop) -5%
Intel Iris Pro Graphics 5200
...
AMD Radeon RX 6900 XT 2738%
3DMark - 3DMark Fire Strike Standard Graphics
min: 1357 avg: 1414 median: 1380.5 (3%) max: 1536 Points
...
AMD Radeon R7 384 Cores (Kaveri Desktop) -1%
Intel Iris Pro Graphics 5200
NVIDIA GeForce GTS 450 9%
...
AMD Radeon RX 6900 XT 3478%
3DMark - 3DMark Ice Storm Graphics
min: 86896 avg: 99805 median: 99804.5 (13%) max: 112713 Points
...
AMD FirePro W2100 -6%
Intel Iris Xe Graphics G7 96EUs -1%
Intel Iris Pro Graphics 5200
AMD Radeon RX Vega 5 1%
NVIDIA GeForce GTX 1660 Ti Max-Q 4%
AMD Radeon RX Vega 11 9%
...
AMD Radeon RX 6800 XT 355%
3DMark 11 - 3DM11 Performance Score
min: 2112 avg: 2216 median: 2217 (5%) max: 2364 Points
...
NVIDIA GeForce GTS 450 -5%
AMD Radeon R7 384 Cores (Kaveri Desktop) -3%
Intel Iris Pro Graphics 5200
...
AMD Radeon RX 6900 XT 1814%
3DMark 11 - 3DM11 Performance GPU
min: 1867 avg: 1916 median: 1923 (3%) max: 1957 Points
...
NVIDIA GeForce GTS 450 -1%
Intel Iris Pro Graphics 5200
Qualcomm Adreno 685 1%
AMD Radeon R7 384 Cores (Kaveri Desktop) 4%
...
AMD Radeon RX 6900 XT 2986%
3DMark Vantage
3DM Vant. Perf. total +3DMark Vantage - 3DM Vant. Perf. total
8692 Points (9%)
...
Intel Iris Pro Graphics 5200
ATI Radeon HD 4850 3%
...
AMD Radeon RX 6800 XT 1010%
3DM Vant. Perf. GPU no PhysX +3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
7362 Points (7%)
...
Intel Iris Pro Graphics 5200
ATI Radeon HD 4850 1%
AMD Radeon R7 512 Cores (Kaveri Desktop) 3%
...
NVIDIA GeForce RTX 3090 1307%
3DMark 2001SE - 3DMark 2001 - Standard
41727 Points (43%)
...
AMD Radeon HD 6450 GDDR5 -8%
Intel Iris Pro Graphics 5200
ATI Radeon HD 5570 6%
NVIDIA GeForce GTX 580 22%
NVIDIA GeForce GTS 450 24%
...
NVIDIA GeForce GTX 1050 (Desktop) 131%
3DMark 03 - 3DMark 03 - Standard
32334 Points (17%)
...
Intel Iris Pro Graphics 5200
ATI Radeon HD 5670 5%
...
3DMark 05 - 3DMark 05 - Standard
16590 Points (24%)
...
AMD Radeon R7 384 Cores (Kaveri Desktop) 0%
Intel Iris Pro Graphics 5200
...
AMD Radeon RX 6700 XT 232%
3DMark 06 3DMark 06 - Standard 1280x1024 +min: 12578 avg: 13123 median: 13123 (24%) max: 13668 Points
...
Intel Iris Pro Graphics 5200
...
AMD Radeon RX 6700 XT 260%
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
20.8 fps (7%)
...
AMD Radeon R7 384 Cores (Kaveri Desktop) -14%
AMD Radeon R7 512 Cores (Kaveri Desktop) -5%
AMD FirePro W4100 -3%
Intel Iris Pro Graphics 5200
...
Unigine Heaven 3.0 - Unigine Heaven 3.0 OpenGL
21.9 fps (10%)
...
Intel Iris Pro Graphics 5200
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 5%
AMD Radeon RX Vega 5 12%
AMD Radeon 540X 13%
...
Unigine Heaven 2.1 - Heaven 2.1 high
26.1 fps (5%)
...
AMD Radeon R7 384 Cores (Kaveri Desktop) -6%
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 3%
NVIDIA Quadro M1200 8%
...
SPECviewperf 11
specvp11 snx-01 +SPECviewperf 11 - specvp11 snx-01
2.3 fps (2%)
...
Intel Iris Pro Graphics 5200
NVIDIA NVS 5400M 3%
...
AMD Radeon Pro Vega 56 6095%
specvp11 tcvis-02 +SPECviewperf 11 - specvp11 tcvis-02
3.1 fps (5%)
...
Intel Iris Pro Graphics 5200
ATI Radeon HD 5850 17%
...
specvp11 sw-02 +SPECviewperf 11 - specvp11 sw-02
15 fps (18%)
...
Intel Iris Pro Graphics 5200
NVIDIA GeForce GTX 580 1%
...
AMD Radeon Pro Vega 56 451%
specvp11 proe-05 +SPECviewperf 11 - specvp11 proe-05
2.2 fps (9%)
...
Intel Iris Pro Graphics 5200
...
NVIDIA Quadro M1200 887%
specvp11 maya-03 +SPECviewperf 11 - specvp11 maya-03
19 fps (14%)
NVIDIA GeForce GTX 580 -92%
...
Intel Iris Pro Graphics 5200
...
AMD Radeon Pro Vega 56 600%
specvp11 lightwave-01 +SPECviewperf 11 - specvp11 lightwave-01
19.9 fps (21%)
...
Intel Iris Pro Graphics 5200
...
AMD Radeon Pro Vega 56 368%
specvp11 ensight-04 +SPECviewperf 11 - specvp11 ensight-04
2.4 fps (1%)
NVIDIA GeForce GTX 580 -59%
Intel Iris Pro Graphics 5200
...
SPECviewperf 12
specvp12 sw-03 +SPECviewperf 12 - specvp12 sw-03
16.7 fps (7%)
...
Intel Iris Pro Graphics 5200
NVIDIA GeForce MX250 0%
Intel Iris Xe MAX Graphics 38%
...
specvp12 snx-02 +SPECviewperf 12 - specvp12 snx-02
2.8 fps (1%)
Intel Iris Xe MAX Graphics -65%
...
NVIDIA GeForce MX250 -25%
Intel Iris Pro Graphics 5200
NVIDIA GeForce GT 1030 (Desktop) 20%
NVIDIA GeForce MX330 21%
...
NVIDIA Titan RTX 9079%
specvp12 showcase-01 +SPECviewperf 12 - specvp12 showcase-01
8.8 fps (4%)
...
AMD FirePro W2100 -5%
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 5%
AMD FirePro W4100 45%
...
AMD Radeon RX 6900 XT 2639%
specvp12 mediacal-01 +SPECviewperf 12 - specvp12 mediacal-01
2.6 fps (2%)
...
Intel Iris Pro Graphics 5200
AMD FirePro W2100 40%
...
specvp12 energy-01 +SPECviewperf 12 - specvp12 energy-01
0.1 fps (0%)
...
Intel Iris Pro Graphics 5200
AMD FirePro W2100 127%
...
AMD Radeon RX 6900 XT 27900%
specvp12 creo-01 +SPECviewperf 12 - specvp12 creo-01
11.7 fps (7%)
...
Intel Iris Xe MAX Graphics -12%
NVIDIA GeForce MX250 -9%
NVIDIA GeForce GT 1030 (Desktop) 0%
Intel Iris Pro Graphics 5200
NVIDIA GeForce MX330 4%
...
specvp12 catia-04 +SPECviewperf 12 - specvp12 catia-04
15.4 fps (5%)
...
AMD FirePro W2100 -7%
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 10%
...
AMD Radeon RX 6900 XT 1796%
Cinebench R10 Cinebench R10 Shading (32bit) +Cinebench R10 - Cinebench R10 Shading (32bit)
9744 pkt. (46%)
...
Intel Iris Pro Graphics 5200
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 2%
...
AMD Radeon RX 5700 XT (Desktop) 117%
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 37.77 avg: 46.5 median: 48 (20%) max: 53.63 fps
...
AMD Radeon HD 8670D -2%
Intel Iris Pro Graphics 5200
...
AMD Radeon RX 6800 XT 266%
Cinebench R15
Cinebench R15 OpenGL 64 Bit +Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 39.15 avg: 48.1 median: 52.3 (15%) max: 52.9 fps
...
Intel Iris Pro Graphics 5200
...
AMD Radeon RX 6800 XT 457%
Cinebench R15 OpenGL Ref. Match 64 Bit +Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
98 % (98%)
...
Intel UHD Graphics 610 0%
AMD Radeon RX Vega 64 0%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 0%
Intel Iris Pro Graphics 5200
Intel Iris Plus Graphics 655 0%
AMD Radeon Pro Vega 20 1%
...
NVIDIA GeForce GTX 1650 (Desktop) 2%
GFXBench (DX / GLBenchmark) 2.7
GLBench 2.7 T-Rex HD Offscreen C24Z16 +GFXBench (DX / GLBenchmark) 2.7 - GLBench 2.7 T-Rex HD Offscreen C24Z16
min: 136 avg: 138 median: 136 (1%) max: 142 fps
...
AMD Radeon R7 512 Cores (Kaveri Desktop) -7%
Intel Iris Pro Graphics 5200
Qualcomm Adreno 680 1%
ARM Mali-G76 MP16 7%
Qualcomm Adreno 640 14%
...
GLBench 2.7 T-Rex HD Onscreen C24Z16 +GFXBench (DX / GLBenchmark) 2.7 - GLBench 2.7 T-Rex HD Onscreen C24Z16
min: 49 avg: 51.5 median: 51.5 (2%) max: 54 fps
...
PowerVR GM9446 -5%
Intel Iris Pro Graphics 5200
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 3%
...
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
min: 307 avg: 325 median: 329 (3%) max: 338 Samples/s
...
NVIDIA GeForce GTX 470 -11%
Intel Iris Pro Graphics 5200
AMD Radeon 540X 6%
...
NVIDIA GeForce GTX 1650 Ti Mobile 2906%
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
min: 447 avg: 461 median: 461 (1%) max: 475 Samples/s
...
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 2%
AMD FirePro W4100 4%
...
AMD Radeon RX 6900 XT 6711%
ComputeMark v2.1 - ComputeMark v2.1 Result
1198 pkt. (3%)
...
Intel UHD Graphics G7 (Lakefield GT2 64 EU) -10%
AMD Radeon R7 384 Cores (Kaveri Desktop) -5%
Intel Iris Pro Graphics 5200
...
NVIDIA GeForce RTX 3090 3726%
- Zakres wyników testów referencyjnych dla tej karty graficznej

- Średnia wartość wyników testów referencyjnych dla tej karty graficzne
* Smaller numbers mean a higher performance
Testy gier
Zamieszczone niżej wyniki pochodzą z testów zrecenzowanych laptopów. Należy pamiętać, że osiągi poszczególnych konfiguracji zależą od zastosowanej pamięci własnej karty (VRAM), zegarów karty (mogą być różne), procesora, ustawień systemu, sterowników i wersji systemu operacyjnego. Tym samym uzyskane wyniki nie muszą być reprezentatywne dla wszystkich laptopów wyposażonych w daną kartę graficzną. By uzyskać szczegółowe informacje o wynikach testów, należy kliknąć na podaną wartość liczbową (fps, czyli kl/s).
...
Intel Iris Pro Graphics 5200
...
AMD Radeon RX 6700 XT 1641%
...
Intel Iris Pro Graphics 5200
...
AMD Radeon RX 6700 XT 2109%
...
Intel Iris Pro Graphics 5200
...
AMD Radeon RX 6800 XT 3208%
» Niegrywalna na większości testowanych laptopów.
...
Intel Iris Pro Graphics 5200
...
NVIDIA GeForce RTX 2080 Ti (Desktop) 1169%
...
Intel Iris Pro Graphics 5200
...
NVIDIA GeForce RTX 2080 Ti (Desktop) 1589%
...
Intel Iris Pro Graphics 5200
...
NVIDIA GeForce RTX 2080 Ti (Desktop)
» Na wszystkich testowanych laptopach grywalna przy ustawieniach low.
...
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 0%
...
NVIDIA Titan X Pascal 562%
...
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 13%
...
NVIDIA GeForce GTX 1080 (Desktop) 664%
...
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 10%
...
NVIDIA GeForce GTX 1080 (Desktop) 947%
...
Intel Iris Pro Graphics 5200
...
NVIDIA Titan X Pascal 1009%
» Niegrywalna na większości testowanych laptopów.
...
Intel Iris Pro Graphics 5200
...
...
Intel Iris Pro Graphics 5200
...
NVIDIA GeForce GTX 1080 (Desktop) 604%
...
Intel Iris Pro Graphics 5200
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach low.
...
Intel Iris Pro Graphics 5200
...
...
Intel Iris Pro Graphics 5200
...
» Niegrywalna na większości testowanych laptopów.
...
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 26%
...
NVIDIA GeForce GTX 1060 (Desktop) 397%
...
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 31%
...
NVIDIA GeForce GTX 1060 (Desktop) 695%
» Na wszystkich testowanych laptopach grywalna przy ustawieniach low.
...
AMD FirePro W2100 -11%
Intel Iris Pro Graphics 5200
...
...
Intel Iris Pro Graphics 5200
...
» Niegrywalna na większości testowanych laptopów.
...
Intel Iris Pro Graphics 5200
...
NVIDIA GeForce GTX 1060 (Desktop) 234%
...
AMD Radeon R7 512 Cores (Kaveri Desktop) -7%
Intel Iris Pro Graphics 5200
...
NVIDIA GeForce GTX 1060 (Desktop) 444%
...
AMD Radeon R7 512 Cores (Kaveri Desktop) -23%
Intel Iris Pro Graphics 5200
...
Intel Iris Pro Graphics 5200
NVIDIA GeForce GTX 950 441%
...
NVIDIA Titan X Pascal 2409%
» Na wszystkich testowanych laptopach grywalna przy ustawieniach ultra.
...
AMD Radeon 540X -13%
NVIDIA GeForce MX230 -9%
AMD Radeon RX Vega 7 -4%
Intel Iris Pro Graphics 5200
AMD Radeon RX Vega 5 5%
NVIDIA GeForce GTX 1650 Mobile 13%
...
NVIDIA GeForce GTX 1080 (Desktop) 112%
...
Intel Iris Pro Graphics 5200
AMD Radeon 540X 13%
NVIDIA GeForce MX230 15%
AMD Radeon RX Vega 7 15%
...
NVIDIA GeForce GTX 1080 (Desktop) 166%
...
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -9%
Intel Iris Pro Graphics 5200
...
NVIDIA GeForce GTX 1080 (Desktop) 391%
AMD Radeon HD 6450 GDDR5 -66%
...
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 0%
Intel Iris Pro Graphics 5200
AMD Radeon 540X 36%
...
NVIDIA GeForce GTX 1080 Ti (Desktop) 575%
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
...
AMD Radeon R7 512 Cores (Kaveri Desktop) -2%
Intel Iris Pro Graphics 5200
NVIDIA GeForce GTX 950 0%
NVIDIA GeForce GTX 960 0%
...
...
AMD Radeon R7 512 Cores (Kaveri Desktop) -6%
Intel Iris Pro Graphics 5200
NVIDIA GeForce GTX 960 21%
...
...
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 12%
...
...
Intel Iris Pro Graphics 5200
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
31 (!) [X] Schenker S413Intel Core i7-4750HQ 2GHz
Iris Pro Graphics 5200
Problem during benchmarking occured: small graphical problems flickering in fullscreenmin:
24 fps, max:
37 fps
fps
+ Porównaj
- Ukryj porównanie
...
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 16%
...
NVIDIA GeForce GTX 1080 (Desktop) 955%
14 (!) [X] Schenker S413Intel Core i7-4750HQ 2GHz
Iris Pro Graphics 5200
Problem during benchmarking occured: small graphical problems fullscreen flickerungmin:
10 fps, max:
18 fps
fps
+ Porównaj
- Ukryj porównanie
...
Intel Iris Pro Graphics 5200
...
» Niegrywalna na większości testowanych laptopów.
...
Intel Iris Pro Graphics 5200
AMD Radeon R7 512 Cores (Kaveri Desktop) 18%
...
...
Intel Iris Pro Graphics 5200
...
» Niegrywalna na większości testowanych laptopów.
...
Intel Iris Pro Graphics 5200
AMD Radeon HD 8670D 3%
...
AMD Radeon RX 6800 XT 2807%
» Niegrywalna na większości testowanych laptopów.
...
AMD Radeon R7 512 Cores (Kaveri Desktop) -11%
Intel Iris Pro Graphics 5200
...
...
Intel Iris Pro Graphics 5200
