AMD Radeon HD 8870M
-
| Producent | AMD |
| Radeon HD 8800M Rodzina | | Radeon HD 8870M | 640 @ 725 MHz | 128 bit @ 4500 MHz | | Radeon HD 8850M | 640 @ 575 - 725 (Boost) MHz | 128 bit @ 4500 MHz | | Radeon HD 8830M | 640 @ 575 MHz | 128 bit @ 2000 MHz |
|
| Architektura | GCN |
| Potoki | 640 - ZJC |
| Zegar rdzenia | 725 MHz |
| Zegar pamięci | 4500 MHz |
| Magistrala | 128 bit |
| Typ pamięci | GDDR5, DDR3 |
| Maks. pamięci | 2048 MB |
| Pamięć współdzielona | nie |
| DirectX | DirectX 11.1, Shader 5.1 |
| Liczba tranzystorów | 1500 mln |
| Technologia | 28 nm |
| Technologie | OpenCL 1.2 |
| Wielkość laptopa | duży |
| Data premiery | 18.12.2012 |
Testy
Performance Rating - 3DMark 11 + Fire Strike + Time Spy
8.1 pt (8%)
...
AMD Radeon HD 8670D -3%
AMD Radeon R7 384 Cores (Kaveri Desktop) 8%
...
3DMark - Cloud Gate Standard Score 1280x720
min: 6393 avg: 10115 median: 11331.5 (62%) max: 11402 Points
| Dell Inspiron 17R-5737 | 4500U | 16384 MB | 725 / 1000 MHz | 2048MB GDDR5 12.100.14.7000 | 6393 |
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 11328 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 11335 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 11402 |
...
NVIDIA GeForce GTS 450 1%
NVIDIA GeForce MX230 3%
AMD Radeon 540X 5%
AMD Radeon HD 7770 6%
...
3DMark - Cloud Gate Standard Graphics 1280x720
min: 13705 avg: 15272 median: 15738.5 (51%) max: 15905 Points
| Dell Inspiron 17R-5737 | 4500U | 16384 MB | 725 / 1000 MHz | 2048MB GDDR5 12.100.14.7000 | 13705 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 15712 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 15765 |
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 15905 |
...
AMD Radeon R7 250 -1%
AMD Radeon 540X -1%
Intel Iris Plus Graphics 655 1%
NVIDIA GeForce MX230 4%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 9%
...
3DMark - Fire Strike Score 1920x1080
min: 1906 avg: 2081 median: 2091 (50%) max: 2235 Points
| Dell Inspiron 17R-5737 | 4500U | 16384 MB | 725 / 1000 MHz | 2048MB GDDR5 12.100.14.7000 | 1906 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 2091 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 2091 |
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 2235 |
...
NVIDIA GeForce GTX 460 768MB -9%
Intel Iris Plus Graphics 655 -6%
AMD Radeon R7 250 -1%
AMD Radeon RX Vega 5 7%
...
3DMark - Fire Strike Graphics 1920x1080
min: 2127 avg: 2203 median: 2168.5 (50%) max: 2346 Points
| Dell Inspiron 17R-5737 | 4500U | 16384 MB | 725 / 1000 MHz | 2048MB GDDR5 12.100.14.7000 | 2127 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 2168 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 2169 |
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 2346 |
...
NVIDIA GeForce GTX 460 768MB -5%
Intel Iris Plus Graphics 655 -4%
AMD Radeon R7 250 -3%
...
3DMark - Ice Storm Standard Graphics 1280x720
min: 42775 avg: 56394 median: 57618 (29%) max: 67563 Points
| Dell Inspiron 17R-5737 | 4500U | 16384 MB | 725 / 1000 MHz | 2048MB GDDR5 12.100.14.7000 | 42775 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 56550 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 58686 |
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 67563 |
AMD Radeon HD 7560D 1%
...
AMD Radeon HD 6870 213%
3DMark 11 - Performance 1280x720
min: 2842 avg: 3202 median: 3292 (50%) max: 3311 points
| Dell Inspiron 17R-5737 | 4500U | 16384 MB | 725 / 1000 MHz | 2048MB GDDR5 12.100.14.7000 | 2842 |
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 3252 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 3292 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 3311 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 3311 |
...
AMD Radeon R7 250 -2%
AMD Radeon HD 6790 1%
Intel Iris Plus Graphics 655 4%
AMD Radeon HD 7770 5%
...
3DMark 11 - Performance GPU 1280x720
min: 2746 avg: 2941 median: 2986 (46%) max: 2996 points
| Dell Inspiron 17R-5737 | 4500U | 16384 MB | 725 / 1000 MHz | 2048MB GDDR5 12.100.14.7000 | 2746 |
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 2980 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 2986 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 2996 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 2996 |
...
AMD Radeon R7 250 -6%
NVIDIA GeForce GTX 460 768MB -4%
AMD Radeon HD 6790 -2%
Intel Iris Plus Graphics 655 4%
AMD Radeon HD 7770 5%
...
3DMark Vantage
P Result 1280x1024 +3DMark Vantage - P Result 1280x1024
min: 8968 avg: 11060 median: 11715 (45%) max: 11840 Points
| Dell Inspiron 17R-5737 | 4500U | 16384 MB | 725 / 1000 MHz | 2048MB GDDR5 12.100.14.7000 | 8968 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 11623 |
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 11807 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 11840 |
...
NVIDIA GeForce GTX 550 Ti -8%
AMD Radeon 540X 4%
ATI Radeon HD 5770 6%
...
P GPU no PhysX 1280x1024 +3DMark Vantage - P GPU no PhysX 1280x1024
min: 9619 avg: 10052 median: 10181.5 (41%) max: 10225 Points
| Dell Inspiron 17R-5737 | 4500U | 16384 MB | 725 / 1000 MHz | 2048MB GDDR5 12.100.14.7000 | 9619 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 10154 |
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 10209 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 10225 |
...
NVIDIA GeForce GTX 550 Ti -1%
ATI Radeon HD 5770 -1%
AMD Radeon 540X 2%
Intel Iris Plus Graphics 655 3%
AMD Radeon R7 250 7%
...
3DMark 05 - Standard 1024x768
18829 Points (59%)
...
NVIDIA NVS 5400M -4%
ATI Radeon HD 5850 -2%
...
3DMark 06 Standard 1280x1024 +min: 14222 avg: 15227 median: 15675 (57%) max: 15785 Points
| Standard 1280x1024 |
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 14222 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 15675 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 15785 |
...
NVIDIA GeForce GTX 550 Ti 2%
ATI Radeon HD 5850 2%
...
Unigine Heaven 3.0 - DX 11, Normal Tessellation, High Shaders 1920x1080
min: 25.4 avg: 26 median: 25.9 (48%) max: 26.7 fps
...
AMD Radeon R7 250 5%
AMD Radeon 540X 16%
...
Unigine Heaven 3.0 - OpenGL, Normal Tessellation, High Shaders 1920x1080
19.4 fps (38%)
...
AMD Radeon R7 512 Cores (Kaveri Desktop) -9%
AMD Radeon R7 384 Cores (Kaveri Desktop) -9%
...
Unigine Heaven 2.1 - high, Tesselation (normal), DirectX11 1280x1024
min: 36.4 avg: 37 median: 37 (42%) max: 37.6 fps
...
NVIDIA GeForce GTS 450 -10%
ATI Radeon HD 5850 2%
AMD Radeon R7 250 3%
...
SPECviewperf 11
Siemens NX 1920x1080 +SPECviewperf 11 - Siemens NX 1920x1080
12.1 fps (19%)
...
AMD Radeon R7 250 -24%
ATI Radeon HD 5850 -18%
AMD Radeon HD 6870 9%
...
Tcvis 1920x1080 +SPECviewperf 11 - Tcvis 1920x1080
6.1 fps (10%)
...
AMD Radeon R7 250 24%
AMD Radeon HD 6870 25%
ATI Radeon HD 5770 25%
...
SolidWorks 1920x1080 +SPECviewperf 11 - SolidWorks 1920x1080
23.4 fps (36%)
...
ATI Radeon HD 5770 17%
AMD Radeon R7 250 20%
AMD Radeon HD 6870 24%
...
Pro/ENGINEER 1920x1080 +SPECviewperf 11 - Pro/ENGINEER 1920x1080
2.4 fps (10%)
...
ATI Radeon HD 5770 10%
AMD Radeon HD 6870 11%
...
Maya 1920x1080 +SPECviewperf 11 - Maya 1920x1080
12.8 fps (11%)
...
ATI Radeon HD 5770 1%
AMD Radeon HD 6870 5%
...
Lightwave 1920x1080 +SPECviewperf 11 - Lightwave 1920x1080
24.6 fps (30%)
...
AMD Radeon R7 250 26%
ATI Radeon HD 5770 32%
AMD Radeon HD 6870 35%
...
Ensight 1920x1080 +SPECviewperf 11 - Ensight 1920x1080
23.6 fps (40%)
...
AMD Radeon HD 6870 -1%
...
Catia 1920x1080 +SPECviewperf 11 - Catia 1920x1080
7.4 fps (11%)
ATI Radeon HD 5770 17%
...
Cinebench R10 Shading 32Bit +Cinebench R10 - Shading 32Bit
min: 7425 avg: 7769 median: 7769 (66%) max: 8113 Points
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 7425 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 8113 |
...
AMD Radeon HD 8570D -4%
AMD Radeon HD 7660D -3%
AMD Radeon 540X -3%
...
Cinebench R11.5 OpenGL 64Bit +Cinebench R11.5 - OpenGL 64Bit
min: 53.85 avg: 55.2 median: 54.7 (47%) max: 57.59 Points
| Samsung ATIV Book 8 Touch 880Z5E X01 | 3635QM | 8192 MB | 400-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 53.85 |
| Samsung 770Z5E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5, Enduro 9.3.5.0 | 54.48 |
| Samsung 770Z7E-S01DE | 3635QM | 8192 MB | 725-775 / 1125 MHz | 2048MB GDDR5 9.3.5.0 | 54.91 |
| Dell Inspiron 17R-5737 | 4500U | 16384 MB | 725 / 1000 MHz | 2048MB GDDR5 12.100.14.7000 | 57.59 |
Intel Iris Plus Graphics 655 -6%
ATI Radeon HD 5670 -3%
...
LuxMark v2.0 64Bit - Room GPUs-only
371 Samples/s (24%)
...
...
LuxMark v2.0 64Bit - Sala GPUs-only
629 Samples/s (40%)
...
NVIDIA GeForce GTX 470 -3%
AMD Radeon 540X 7%
...
- Zakres wyników testów referencyjnych dla tej karty graficznej
- Średnia wartość wyników testów referencyjnych dla tej karty graficzne
* Smaller numbers mean a higher performance
Testy gier
Zamieszczone niżej wyniki pochodzą z testów zrecenzowanych laptopów. Należy pamiętać, że osiągi poszczególnych konfiguracji zależą od zastosowanej pamięci własnej karty (VRAM), zegarów karty (mogą być różne), procesora, ustawień systemu, sterowników i wersji systemu operacyjnego. Tym samym uzyskane wyniki nie muszą być reprezentatywne dla wszystkich laptopów wyposażonych w daną kartę graficzną. By uzyskać szczegółowe informacje o wynikach testów, należy kliknąć na podaną wartość liczbową (fps, czyli kl/s).
...
AMD Radeon HD 7660D 33%
AMD Radeon HD 8570D 38%
...
...
AMD Radeon HD 7660D 5%
AMD Radeon HD 8570D 8%
...
...
AMD Radeon HD 8670D -13%
AMD Radeon R7 384 Cores (Kaveri Desktop) -4%
AMD Radeon R7 512 Cores (Kaveri Desktop) -4%
...
...
AMD Radeon HD 8670D -38%
AMD Radeon R7 384 Cores (Kaveri Desktop) -28%
AMD Radeon R7 512 Cores (Kaveri Desktop) -28%
...
» Niegrywalna na większości testowanych laptopów.
...
AMD Radeon HD 8570D 10%
AMD Radeon HD 8670D 10%
...
...
AMD Radeon HD 8570D -14%
AMD Radeon HD 8670D 9%
...
...
AMD Radeon HD 8670D -7%
...
...
AMD Radeon HD 8670D -32%
...
» Niegrywalna na większości testowanych laptopów.
...
AMD Radeon HD 7480D -1%
...
...
AMD Radeon HD 7480D -20%
...
...
AMD Radeon HD 8670D -9%
AMD Radeon R7 250 70%
...
...
AMD Radeon HD 8670D -47%
AMD Radeon R7 250 16%
...
» Niegrywalna na większości testowanych laptopów.
AMD Radeon HD 7660D -10%
...
...
AMD Radeon HD 8670D -5%
...
...
AMD Radeon R7 250 21%
...
...
AMD Radeon R7 250 -1%
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
...
AMD Radeon HD 7560D 21%
AMD Radeon HD 8670D 30%
...
AMD Radeon HD 7770 210%
...
AMD Radeon HD 7560D 3%
AMD Radeon HD 8670D 25%
...
AMD Radeon HD 7770 180%
...
AMD Radeon HD 7560D -5%
AMD Radeon HD 8570D 3%
AMD Radeon HD 8670D 21%
...
AMD Radeon HD 7770 159%
...
AMD Radeon HD 8570D -28%
AMD Radeon HD 7660D -26%
AMD Radeon HD 8670D -13%
AMD Radeon HD 7770 96%
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach ultra.
...
AMD Radeon HD 7770 26%
...
...
AMD Radeon HD 7770 29%
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
...
AMD Radeon HD 7560D -16%
AMD Radeon HD 8570D -10%
AMD Radeon HD 7660D -7%
AMD Radeon HD 8670D 1%
...
...
AMD Radeon HD 7560D -10%
AMD Radeon HD 8570D -8%
AMD Radeon HD 7660D -6%
AMD Radeon HD 8670D 7%
...
...
AMD Radeon HD 7660D -20%
AMD Radeon HD 8670D -6%
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach low.
...
AMD Radeon HD 7770 -5%
...
...
AMD Radeon HD 7770 -18%
...
...
AMD Radeon HD 7770 -5%
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
...
AMD Radeon HD 8570D -26%
AMD Radeon HD 8670D -16%
...
...
AMD Radeon HD 7770 24%
...
AMD Radeon HD 8570D -60%
AMD Radeon HD 8670D -50%
AMD Radeon HD 7770 28%
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
...
AMD Radeon HD 7660D -26%
AMD Radeon HD 8670D -17%
...
...
AMD Radeon HD 7770 26%
...
AMD Radeon HD 7770 26%
» Na wszystkich testowanych laptopach grywalna przy ustawieniach ultra.
...
NVIDIA GeForce GTS 450 -11%
...
AMD Radeon HD 7770 53%
...
NVIDIA GeForce GTS 450 -17%
AMD Radeon R7 250 11%
...
AMD Radeon HD 7770 51%
...
AMD Radeon R7 250 -6%
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach low.
...
AMD Radeon HD 7560D -10%
AMD Radeon HD 8570D -5%
AMD Radeon HD 7660D -2%
AMD Radeon R7 512 Cores (Kaveri Desktop) 6%
AMD Radeon HD 8670D 6%
...
...
AMD Radeon R7 512 Cores (Kaveri Desktop) -9%
AMD Radeon R7 250 35%
...
...
AMD Radeon R7 250 -7%
AMD Radeon HD 7770 38%
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
...
...
...
AMD Radeon R7 250 21%
...
...
AMD Radeon R7 250 0%
AMD Radeon HD 7770 19%
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
...
AMD Radeon HD 7660D -7%
AMD Radeon HD 8570D -4%
AMD Radeon HD 8670D 9%
...
...
Intel Iris Plus Graphics 655 7%
...
...
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 1%
Intel Iris Plus Graphics 655 2%
...
...
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -2%
AMD Radeon R7 250 5%
AMD Radeon 540X 15%
...
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
...
AMD Radeon HD 7560D -11%
AMD Radeon HD 7660D -2%
AMD Radeon HD 7550M -2%
AMD Radeon HD 8670D 1%
...
...
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 12%
NVIDIA GeForce GTX 470 20%
...
...
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -12%
