Intel HD Graphics 520
HD Graphics 520 to układ grafiki z niskonapięciowych procesorów Skylake (czyli m.in. Core i3-6006U, Core i5-6200U, Core i7-6500U).
| Producent | Intel |
| Gen. 9 Rodzina | |
| Nazwa robocza | Skylake GT2 |
| Architektura | Gen. 9 Skylake |
| Potoki | 24 - ZJC |
| Zegar rdzenia | 300 - 1050 (Boost) MHz |
| Magistrala | 64/128 bit |
| Typ pamięci | DDR3/DDR4 |
| Pamięć współdzielona | tak |
| DirectX | DirectX 12_1 |
| Technologia | 14 nm |
| Technologie | QuickSync |
| Data premiery | 01.09.2015 |
Testy
Performance Rating - 3DMark 11 + Fire Strike + Time Spy
5.3 pt (6%)
...
Intel UHD Graphics G7 (Lakefield GT2 64 EU) -2%
AMD Radeon HD 7560D -2%
...
AMD Radeon RX 6800 XT 1698%
3DMark - 3DMark Time Spy Score
297 Points (2%)
| Model | CPU | GPU | RAM | Wartość |
|---|
Asus Transformer 3 Pro T303UA-GN050T  | 6500U | HD Graphics 520 933 / 933 MHz 0 GB | 16 GB | 297 |
...
Intel UHD Graphics 610 -25%
NVIDIA GeForce GT 710 -11%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) 31%
...
AMD Radeon RX 6900 XT 5809%
3DMark - 3DMark Time Spy Graphics
263 Points (1%)
| Model | CPU | GPU | RAM | Wartość |
|---|
| Asus Transformer 3 Pro T303UA-GN050T | 6500U | HD Graphics 520 933 / 933 MHz 0 GB | 16 GB | 263 |
...
Intel UHD Graphics 610 -26%
NVIDIA GeForce GT 710 -14%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) 33%
...
NVIDIA GeForce RTX 3090 7206%
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 50874 avg: 70431 median: 73656 (12%) max: 88058 Points
...
Qualcomm Adreno 620 -5%
NVIDIA GeForce GT 710 0%
ARM Mali-G76 MP16 2%
ATI Radeon HD 4850 3%
ARM Mali-G77 MP11 6%
...
NVIDIA GeForce RTX 3080 Laptop GPU 689%
3DMark - 3DMark Ice Storm Extreme Graphics
min: 27001 avg: 38067 median: 39969 (5%) max: 49514 Points
...
NVIDIA GeForce GT 710 -8%
...
AMD Radeon RX 6800 XT 1009%
3DMark - 3DMark Cloud Gate Score
min: 3915 avg: 5379 median: 5357.5 (7%) max: 6737 Points
...
AMD Radeon HD 7560D -6%
AMD Radeon HD 8570D 3%
AMD Radeon HD 7660D 4%
...
AMD Radeon RX 6800 XT 1233%
3DMark - 3DMark Cloud Gate Graphics
min: 4724 avg: 6747 median: 6700.5 (3%) max: 8842 Points
...
AMD Radeon HD 7560D -5%
AMD Radeon HD 8570D 5%
NVIDIA GeForce GT 710 8%
AMD Radeon HD 7660D 10%
...
NVIDIA GeForce RTX 3090 2792%
3DMark - 3DMark Fire Strike Standard Score
min: 536 avg: 748 median: 752 (2%) max: 961 Points
...
AMD Radeon HD 7560D 0%
...
AMD Radeon RX 6900 XT 5122%
3DMark - 3DMark Fire Strike Standard Graphics
min: 564 avg: 800 median: 803.5 (2%) max: 1056 Points
...
AMD Radeon HD 7560D -1%
...
AMD Radeon RX 6900 XT 6223%
3DMark - 3DMark Ice Storm Graphics
min: 633 avg: 56112 median: 56183 (7%) max: 82961 Points
...
AMD Radeon HD 7560D 1%
Intel Iris Xe Graphics G7 80EUs 3%
...
AMD Radeon RX 6800 XT 709%
3DMark 11 - 3DM11 Performance Score
min: 1135 avg: 1433 median: 1435.5 (3%) max: 1700 Points
...
AMD Radeon HD 7660D 9%
...
AMD Radeon RX 6900 XT 2860%
3DMark 11 - 3DM11 Performance GPU
min: 1060 avg: 1296 median: 1293.5 (2%) max: 1520 Points
...
AMD Radeon HD 8570D -9%
...
AMD Radeon RX 6900 XT 4462%
3DMark Vantage
3DM Vant. Perf. total +3DMark Vantage - 3DM Vant. Perf. total
min: 4381 avg: 5299 median: 5722 (6%) max: 5884 Points
...
NVIDIA NVS 5400M -2%
NVIDIA GeForce GT 240 GDDR5 -1%
AMD Radeon HD 8570D 0%
...
AMD Radeon RX 6800 XT 1721%
3DM Vant. Perf. GPU no PhysX +3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 3680 avg: 4547 median: 4966 (5%) max: 5052 Points
...
NVIDIA NVS 5400M -3%
AMD Radeon HD 8570D -1%
...
NVIDIA GeForce RTX 3090 2177%
3DMark 2001SE - 3DMark 2001 - Standard
min: 20229 avg: 23729 median: 23728.5 (25%) max: 27228 Points
...
AMD Radeon HD 6550D 0%
...
NVIDIA GeForce GTX 1050 (Desktop) 306%
3DMark 03 - 3DMark 03 - Standard
min: 14683 avg: 17873 median: 18240 (10%) max: 20522 Points
...
AMD Radeon HD 7480D -5%
...
3DMark 05 - 3DMark 05 - Standard
min: 9082 avg: 11565 median: 10910 (16%) max: 15357 Points
...
AMD Radeon HD 8470D -3%
AMD Radeon HD 6550D 8%
...
AMD Radeon RX 6700 XT 376%
3DMark 06 3DMark 06 - Standard 1280x1024 +min: 5463 avg: 8344 median: 8656 (16%) max: 9977 Points
...
AMD Radeon HD 7560D -2%
...
AMD Radeon RX 6700 XT 467%
3DMark 06 - Standard 1280x720 +6847 Points (13%)
SPECviewperf 11
specvp11 snx-01 +SPECviewperf 11 - specvp11 snx-01
min: 2.06 avg: 2.3 median: 2.3 (2%) max: 2.58 fps
...
NVIDIA NVS 5400M 1%
...
AMD Radeon Pro Vega 56 5987%
specvp11 tcvis-02 +SPECviewperf 11 - specvp11 tcvis-02
min: 2.32 avg: 2.9 median: 2.9 (5%) max: 3.45 fps
...
...
specvp11 sw-02 +SPECviewperf 11 - specvp11 sw-02
min: 13.26 avg: 15.9 median: 15.7 (19%) max: 18.81 fps
...
NVIDIA GeForce GTX 580 -5%
ATI Radeon HD 5850 4%
...
AMD Radeon Pro Vega 56 420%
specvp11 proe-05 +SPECviewperf 11 - specvp11 proe-05
min: 1.99 avg: 2.4 median: 2.4 (10%) max: 2.81 fps
...
ATI Radeon HD 5770 10%
...
NVIDIA Quadro M1200 832%
specvp11 maya-03 +SPECviewperf 11 - specvp11 maya-03
min: 10.4 avg: 17.4 median: 17.1 (13%) max: 23.97 fps
NVIDIA GeForce GTX 580 -92%
...
AMD Radeon R9 280X -8%
...
AMD Radeon Pro Vega 56 664%
specvp11 lightwave-01 +SPECviewperf 11 - specvp11 lightwave-01
min: 15.49 avg: 19.4 median: 19.8 (21%) max: 23.36 fps
...
...
AMD Radeon Pro Vega 56 380%
specvp11 ensight-04 +SPECviewperf 11 - specvp11 ensight-04
min: 2.39 avg: 2.9 median: 2.9 (1%) max: 3.3 fps
...
...
SPECviewperf 12
specvp12 sw-03 +SPECviewperf 12 - specvp12 sw-03
22.6 fps (10%)
| Model | CPU | GPU | RAM | Wartość |
|---|
| Lenovo ThinkPad T460s-20FA003GGE | 6600U | HD Graphics 520 1050 / 1066 MHz | 12 GB | 22.64 |
...
NVIDIA GeForce MX250 -26%
Intel Iris Xe MAX Graphics 2%
NVIDIA GeForce GT 1030 (Desktop) 12%
...
specvp12 snx-02 +SPECviewperf 12 - specvp12 snx-02
3 fps (1%)
Intel Iris Xe MAX Graphics -67%
...
NVIDIA GeForce GT 1030 (Desktop) 14%
NVIDIA GeForce MX330 15%
...
NVIDIA Titan RTX 8612%
specvp12 showcase-01 +SPECviewperf 12 - specvp12 showcase-01
6.1 fps (3%)
...
...
AMD Radeon RX 6900 XT 3883%
specvp12 mediacal-01 +SPECviewperf 12 - specvp12 mediacal-01
1.7 fps (2%)
...
...
specvp12 maya-04 +SPECviewperf 12 - specvp12 maya-04
10.9 fps (5%)
| Model | CPU | GPU | RAM | Wartość |
|---|
| Lenovo ThinkPad T460s-20FA003GGE | 6600U | HD Graphics 520 1050 / 1066 MHz | 12 GB | 10.89 |
...
AMD FirePro W2100 26%
...
NVIDIA GeForce RTX 3060 Ti 1707%
specvp12 energy-01 +SPECviewperf 12 - specvp12 energy-01
0.1 fps (0%)
...
...
AMD Radeon RX 6900 XT 51233%
specvp12 creo-01 +SPECviewperf 12 - specvp12 creo-01
10.2 fps (6%)
| Model | CPU | GPU | RAM | Wartość |
|---|
| Lenovo ThinkPad T460s-20FA003GGE | 6600U | HD Graphics 520 1050 / 1066 MHz | 12 GB | 10.15 |
...
Intel Iris Xe MAX Graphics 1%
NVIDIA GeForce MX250 4%
NVIDIA GeForce GT 1030 (Desktop) 15%
NVIDIA GeForce MX330 20%
...
specvp12 catia-04 +SPECviewperf 12 - specvp12 catia-04
11.6 fps (4%)
| Model | CPU | GPU | RAM | Wartość |
|---|
| Lenovo ThinkPad T460s-20FA003GGE | 6600U | HD Graphics 520 1050 / 1066 MHz | 12 GB | 11.62 |
...
NVIDIA GeForce MX250 -21%
AMD FirePro W2100 23%
...
AMD Radeon RX 6900 XT 2417%
Cinebench R10 Cinebench R10 Shading (32bit) +Cinebench R10 - Cinebench R10 Shading (32bit)
min: 4559 avg: 7464 median: 7578 (36%) max: 9184 pkt.
...
AMD Radeon HD 7560D -2%
AMD Radeon R7 512 Cores (Kaveri Desktop) -1%
AMD Radeon HD 8570D 0%
AMD Radeon HD 7660D 1%
AMD Radeon 540X 1%
...
AMD Radeon RX 5700 XT (Desktop) 184%
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 7.25 avg: 29.5 median: 30.1 (13%) max: 41.82 fps
...
NVIDIA NVS 5400M -5%
ATI Radeon HD 5570 2%
...
AMD Radeon RX 6800 XT 476%
Cinebench R15
Cinebench R15 OpenGL 64 Bit +Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 23.59 avg: 36.7 median: 37 (10%) max: 45.76 fps
