ATI Mobility Radeon HD 3650

ATI Mobility Radeon HD 3650

-

Mobility Radeon 3000 Rodzina

Mobility Radeon HD 3670 120 @ 0.68 GHz128 bit @ 800 MHz
Mobility Radeon HD 3650 120 @ 0.6 GHz128 bit @ 700 MHz
Nazwa roboczaM86
ArchitekturaRV6xx
Potoki120 - ZJC
Zegar rdzenia600 MHz
Zegar pamięci700 MHz
Magistrala128 bit
Typ pamięciDDR2/GDDR3/GDDR4
Pamięć współdzielonanie
APIDirectX 10.1, Shader 4.1
Pobór prądu30 W
Liczba tranzystorów378 mln
Technologia55 nm
TechnologiePowerplay 7.0, PCI-E 2.0
Wielkość laptopaśredni
Data premiery07.01.2008
Witryna producentahttp://ati.amd.com/de/products/mobilityr...

Testy

3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 570     avg: 805     median: 855 (0%)     max: 990 Points
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 446     avg: 635     median: 669 (0%)     max: 791 Points
3DMark 2001SE - 3DMark 2001 - Standard
min: 14861     avg: 22425     median: 23042 (24%)     max: 27281 Points
3DMark 03 - 3DMark 03 - Standard
min: 8302     avg: 9596     median: 9268.5 (5%)     max: 11453 Points
3DMark 05 - 3DMark 05 - Standard
min: 6527     avg: 7539     median: 7295 (8%)     max: 8780 Points
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 3321     avg: 3507     median: 3360 (5%)     max: 3890 Points
3DMark 06 - Standard 1280x800 +
3DMark 06
min: 3302     avg: 3607     median: 3667 (5%)     max: 3853 Points
3DMark 06 - Standard 1280x768 +
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 2575     avg: 3323     median: 3291 (2%)     max: 4556 pkt.
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
5.7 fps (2%)
- Zakres wyników testów referencyjnych dla tej karty graficznej
- Średnia wartość wyników testów referencyjnych dla tej karty graficzne
* Smaller numbers mean a higher performance

Testy gier

Zamieszczone niżej wyniki pochodzą z testów zrecenzowanych laptopów. Należy pamiętać, że osiągi poszczególnych konfiguracji zależą od zastosowanej pamięci własnej karty (VRAM), zegarów karty (mogą być różne), procesora, ustawień systemu, sterowników i wersji systemu operacyjnego. Tym samym uzyskane wyniki nie muszą być reprezentatywne dla wszystkich laptopów wyposażonych w daną kartę graficzną. By uzyskać szczegółowe informacje o wynikach testów, należy kliknąć na podaną wartość liczbową (fps, czyli kl/s).

Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
low 1024x768
33.8 43.4 48.2 48.5 ~ 43 fps    + Porównaj
med. 1024x768
18.1 21.5 21.5 23.2 ~ 21 fps    + Porównaj
high 1024x768
9.4 10 10 11.2 11.2 13.3 ~ 11 fps    + Porównaj
» Na większości testowanych laptopów grywalna przy ustawieniach low.
Additional Benchmarks
Low 0xAF 0xAA 1280x800
31.1
Medium 0xAF 0xAA 1280x800
15
19.2
19.2
Low 0xAF 0xAA 1440x900
23
High 1280x800
10.8
High 800x600
14
Low 1920x1200
14
Med 0xAF 0xAA 1600x1200
9
High 0xAF 0xAA 800x600
14.6
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
low 1024x768
37.5 37.8 43.1 43.3 ~ 40 fps    + Porównaj
med. 1024x768
15.7 17.8 18.5 19.5 ~ 18 fps    + Porównaj
high 1024x768
8 8.1 9 9 9.3 10.8 ~ 9 fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach low.
Additional Benchmarks
Low 0xAF 0xAA 1280x800
31.8
Medium 0xAF 0xAA 1280x800
13
16.4
Low 0xAF 0xAA 1440x900
22
Low 1920x1200
13
High 0xAF 0xAA 1280x800
9.1
Med 0xAF 0xAA 1600x1200
8
High 0xAF 0xAA 800x600
12.1
12
World in Conflict - Benchmark

World in Conflict - Benchmark

2007
med. 1024x768
33 33 ~ 33 fps    + Porównaj
high 1024x768
8 9 ~ 9 fps    + Porównaj
» Niegrywalna na większości testowanych laptopów.
Additional Benchmarks
Medium 0xAF 0xAA 1280x800
23
High 2xAF 2xAA 1280x800
6
Medium 0xAF 0xAA 1680x1050
17
High 2xAF 2xAA 1680x1050
5
Medium 0xAF 0xAA 1400x1050
20
High 0xAF 0xAA 1400x1050
5
The Elder Scrolls IV - Oblivion

The Elder Scrolls IV - Oblivion

2006
high 1280x800
36  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
F.E.A.R.

F.E.A.R.

2005
low 640x480
30 31 165 166 220 309 309 ~ 176 fps    + Porównaj
med. 800x600
28 29 29 84 88 94 101 ~ 65 fps    + Porównaj
high 1024x768
19 22 22 24 24 25 25 ~ 23 fps    + Porównaj
» Na większości testowanych laptopów grywalna przy ustawieniach med..
Doom 3

Doom 3

2004
low 640x480
120 129.7 160.4 173.5 ~ 146 fps    + Porównaj
med. 640x480
119.9 133.8 154.2 169.2 ~ 144 fps    + Porównaj
high 800x600
104.6 105.5 119.2 135.8 ~ 116 fps    + Porównaj
ultra 1024x768
70.9 75.3 77.4 93.1 ~ 79 fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach ultra.
Quake 3 Arena - Timedemo

Quake 3 Arena - Timedemo

1999
high 1024x768
322 335.8 423.5 464.3 ~ 386 fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
