ATI Mobility Radeon 9800

ATI Mobility Radeon 9800

-

ProducentATI
Mobility Radeon 9x00 Rodzina
Mobility Radeon 9800 8/4 cores @ 0.35 GHz256 bit @ 300 MHz
Mobility Radeon 9700 4/2 cores @ 0.45 GHz128 / 64 bit @ 275 MHz
Mobility Radeon 9600 4/2 cores @ 0.3 GHz128 / 64 bit @ 300 MHz
Mobility Radeon 9550 4/2 cores @ 0.21 GHz64 bit @ 183 MHz
Nazwa roboczaM18
Potoki8 / 4 pikseli / wierzcholków
Zegar rdzenia350 MHz
Zegar pamięci300 MHz
Magistrala256 bit
Typ pamięciDDR2 / DDR3
Maks. pamięci256 MB
Pamięć współdzielonanie
DirectXDirectX 9, Shader 2.0
Liczba tranzystorów110 mln
Technologia130 nm
TechnologiePowerplay
Wielkość laptopaduży
Data premiery01.07.2004
Inne-
Witryna producentahttp://www.ati.com/products/mobilityrade...

Testy

3DMark 2001SE - 3DMark 2001 - Standard
17800 Points (18%)
+ 1 Więcej danych   + Pokaż wykres porównawczy
3DMark 03 - 3DMark 03 - Standard
6500 Points (3%)
+ 1 Więcej danych   + Pokaż wykres porównawczy
3DMark 05 - 3DMark 05 - Standard
2800 Points (4%)
+ 1 Więcej danych   - Ukryj wykres porównawczy
3DMark 06 3DMark 06 - Score Unknown Settings +
- Zakres wyników testów referencyjnych dla tej karty graficznej
- Średnia wartość wyników testów referencyjnych dla tej karty graficzne
* Smaller numbers mean a higher performance

Więcej informacji w rankingu płynności w grach

v1.15

Brak recenzji dla tej karty graficznej.
