ATI Mobility Radeon HD 2300

ATI Mobility Radeon HD 2300

-

ProducentATI
Nazwa roboczaM71
ArchitekturaRV5xx
Potoki4 / 2 pikseli / wierzcholków
Zegar rdzenia480 MHz
Zegar pamięci400 MHz
Magistrala128 bit
Typ pamięciDDR1/DDR2/GDDR3
Pamięć współdzielonanie
DirectXDirectX 9c, Shader 3.0
Liczba tranzystorów115 mln
Technologia90 nm
TechnologiePower Play 6.0, Avivo Video
Data premiery01.03.2007
Witryna producentahttp://ati.amd.com/products/MobilityRade...

Testy

3DMark 2001SE - 3DMark 2001 - Standard
9000 Points (9%)
+ 1 Więcej danych   + Pokaż wykres porównawczy
3DMark 03 - 3DMark 03 - Standard
3561 Points (2%)
+ 1 Więcej danych   + Pokaż wykres porównawczy
3DMark 05 - 3DMark 05 - Standard
1902 Points (3%)
+ 1 Więcej danych   - Ukryj wykres porównawczy
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06 - Standard 1024x768 +
- Zakres wyników testów referencyjnych dla tej karty graficznej
- Średnia wartość wyników testów referencyjnych dla tej karty graficzne
* Smaller numbers mean a higher performance

Więcej informacji w rankingu płynności w grach

v1.16

Recenzje laptopów ATI Mobility Radeon HD 2300 z kartą graficzną

Fujitsu-Siemens Amilo Pi 2530: Intel Core 2 Duo T7100, 15.40", 2.9 kg
  Recenzja » Recenzja Fujitsu-Siemens Amilo Pi 2530
