ATI Mobility Radeon HD 3450

ATI Mobility Radeon HD 3450

-

Mobility Radeon HD 3000 Rodzina

Mobility Radeon HD 3870 320 @ 0.66 GHz256 bit @ 850 MHz
Mobility Radeon HD 3470 Hybrid X2 80
Mobility Radeon HD 3470 40 @ 0.68 GHz64 bit @ 800 MHz
Mobility Radeon HD 3450 40 @ 0.5 GHz64 bit @ 700 MHz
Nazwa roboczaM82
ArchitekturaRV6xx
Potoki40 - ZJC
Zegar rdzenia500 MHz
Zegar pamięci700 MHz
Magistrala64 bit
Typ pamięciDDR2/GDDR3
Pamięć współdzielonanie
APIDirectX 10.1, Shader 4.1
Pobór prądu12 W
Liczba tranzystorów181 mln
Technologia55 nm
TechnologieDisplayPort
Data premiery08.01.2007
Witryna producentaati.amd.com

Testy

3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 200     avg: 306.5     median: 306.5 (0%)     max: 413 Points
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 150     avg: 234     median: 234 (0%)     max: 318 Points
3DMark 2001SE - 3DMark 2001 - Standard
min: 10800     avg: 12534     median: 12859 (13%)     max: 13943 Points
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06 - Standard 1280x800 +
3DMark 06
min: 1790     avg: 1908     median: 1823 (2%)     max: 2112 Points
Cinebench R10 Cinebench R10 Shading (32bit) +
- Zakres wyników testów referencyjnych dla tej karty graficznej
- Średnia wartość wyników testów referencyjnych dla tej karty graficzne
* Smaller numbers mean a higher performance

Testy gier

Zamieszczone niżej wyniki pochodzą z testów zrecenzowanych laptopów. Należy pamiętać, że osiągi poszczególnych konfiguracji zależą od zastosowanej pamięci własnej karty (VRAM), zegarów karty (mogą być różne), procesora, ustawień systemu, sterowników i wersji systemu operacyjnego. Tym samym uzyskane wyniki nie muszą być reprezentatywne dla wszystkich laptopów wyposażonych w daną kartę graficzną. By uzyskać szczegółowe informacje o wynikach testów, należy kliknąć na podaną wartość liczbową (fps, czyli kl/s).

Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
low 1024x768
22.8 25.5 ~ 24 fps    + Porównaj
med. 1024x768
8.9 9.6 ~ 9 fps    + Porównaj
high 1024x768
4.5 5.6 ~ 5 fps    + Porównaj
» Niegrywalna na większości testowanych laptopów.
Additional Benchmarks
Low 0xAF 0xAA 1280x800
18.3
Medium 0xAF 0xAA 1280x800
7.7
High 1280x800
4.5
High 800x600
7.9
Low 0xAF 0xAA 800x600
29.3
Med 0xAF 0xAA 800x600
13.3
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
low 1024x768
19.6 21.6 ~ 21 fps    + Porównaj
med. 1024x768
7.8 7.8 ~ 8 fps    + Porównaj
high 1024x768
4 4.5 ~ 4 fps    + Porównaj
» Niegrywalna na większości testowanych laptopów.
Additional Benchmarks
Low 0xAF 0xAA 1280x800
15.8
Medium 0xAF 0xAA 1280x800
6.5
High 0xAF 0xAA 1280x800
3.8
Med 0xAF 0xAA 800x600
11.2
Low 0xAF 0xAA 800x600
26.3
High 0xAF 0xAA 800x600
6.4
World in Conflict - Benchmark

World in Conflict - Benchmark

2007
med. 1024x768
14  fps    + Porównaj
high 1024x768
4  fps    + Porównaj
» Niegrywalna na większości testowanych laptopów.
Additional Benchmarks
Medium 0xAF 0xAA 1280x800
11
Medium 0xAF 0xAA 1440x900
10
F.E.A.R.

F.E.A.R.

2005
low 640x480
232 281 ~ 257 fps    + Porównaj
med. 800x600
27 47 ~ 37 fps    + Porównaj
high 1024x768
11 12 ~ 12 fps    + Porównaj
» Na większości testowanych laptopów grywalna przy ustawieniach med..
Doom 3

Doom 3

2004
low 640x480
75.1  fps    + Porównaj
med. 640x480
74.2  fps    + Porównaj
high 800x600
51.1  fps    + Porównaj
ultra 1024x768
33.9  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
Quake 3 Arena - Timedemo

Quake 3 Arena - Timedemo

1999
high 1024x768
255  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
lowmed.highultraQHD4K
Crysis - GPU Benchmark2495
Crysis - CPU Benchmark2184
World in Conflict - Benchmark144
F.E.A.R.2573712
Doom 375.174.251.133.9
Quake 3 Arena - Timedemo255
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
2

1
1
3
1
1
4
1

1

1







Więcej informacji w rankingu płynności w grach
