AMD Radeon HD 8690M

AMD Radeon HD 8690M

-

Radeon HD 8600M Rodzina

Radeon HD 8690M 384 @ 0.78 GHz64 bit @ 4500 MHz
Radeon HD 8650M 384 @ 0.65 GHz64 bit @ 4500 MHz
Radeon HD 8650G + HD 8670M Dual Graphics 768 @ 0.72 GHz64 bit @ 1800 - 2000 MHz
Radeon HD 8550G + HD 8670M Dual Graphics 640 @ 0.72 GHz64 bit @ 2000 MHz
Radeon HD 8670M 384 @ 0.78 GHz64 bit @ 2000 MHz
ArchitekturaGCN
Potoki384 - ZJC
Zegar rdzenia775 MHz
Zegar pamięci4500 MHz
Magistrala64 bit
Typ pamięciGDDR5
Maks. pamięci1024 MB
Pamięć współdzielonanie
APIDirectX 11.1, Shader 5.0
Technologia28 nm
Wielkość laptopaśredni
Data premiery16.11.2012

Testy

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.6 pt (2%)
0.06605 -88%
...
0.525 -5%
0.529 -4%
0.532 -3%
0.534 -3%
0.536 -3%
Intel UHD Graphics 24EUs (Alder Lake-N)
0.539 -2%
0.546 -1%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H)
0.548 -1%
0.551 0%
AMD Radeon HD 8690M
0.551
0.552 0%
0.558 1%
0.573 4%
0.581 5%
0.585 6%
Intel UHD Graphics G7 (Lakefield GT2 64 EU)
0.59 7%
0.594 8%
0.601 9%
0.609 11%
...
21.1 3729%
max:
33.3 5944%
0%
100%
3DMark - 3DMark Cloud Gate Graphics
7930 Points (2%)
3DMark - 3DMark Fire Strike Standard Score
1151 Points (2%)
3DMark - 3DMark Fire Strike Standard Graphics
1210 Points (1%)
3DMark - 3DMark Ice Storm Graphics
69892 Points (8%)
3DMark 11 - 3DM11 Performance Score
1790 Points (2%)
3DMark 11 - 3DM11 Performance GPU
1600 Points (1%)
171.8 -89%
...
1499 -6%
1529 -4%
1539 -4%
1541 -4%
Intel UHD Graphics 24EUs (Alder Lake-N)
1569 -2%
1577 -1%
1583 -1%
1588 -1%
1597 0%
AMD Radeon HD 8690M
1600
Intel UHD Graphics Xe 16EUs (Tiger Lake-H)
1602 0%
1621 1%
Intel UHD Graphics (Jasper Lake 32 EU)
1625 2%
1628 2%
1652 3%
1656 4%
1671 4%
1674 5%
1684 5%
...
59943 3646%
max:
106023 6526%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
41 fps (2%)
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
95 % (95%)
- Zakres wyników testów referencyjnych dla tej karty graficznej
- Średnia wartość wyników testów referencyjnych dla tej karty graficzne
* Smaller numbers mean a higher performance

Testy gier

Zamieszczone niżej wyniki pochodzą z testów zrecenzowanych laptopów. Należy pamiętać, że osiągi poszczególnych konfiguracji zależą od zastosowanej pamięci własnej karty (VRAM), zegarów karty (mogą być różne), procesora, ustawień systemu, sterowników i wersji systemu operacyjnego. Tym samym uzyskane wyniki nie muszą być reprezentatywne dla wszystkich laptopów wyposażonych w daną kartę graficzną. By uzyskać szczegółowe informacje o wynikach testów, należy kliknąć na podaną wartość liczbową (fps, czyli kl/s).

GRID 2

GRID 2

2013
low 1024x768
101  fps    + Porównaj
med. 1366x768
52.3  fps    + Porównaj
high 1366x768
35.6  fps    + Porównaj
ultra 1920x1080
18.9  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
low 1024x768
52.3  fps    + Porównaj
med. 1366x768
36  fps    + Porównaj
high 1366x768
28.6  fps    + Porównaj
ultra 1920x1080
19.3  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
low 1024x768
59.9  fps    + Porównaj
med. 1366x768
33.6  fps    + Porównaj
high 1366x768
22.1  fps    + Porównaj
ultra 1920x1080
12.5  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach low.
Crysis 3

Crysis 3

2013
low 1024x768
28.5  fps    + Porównaj
med. 1366x768
15.4  fps    + Porównaj
high 1366x768
10.3  fps    + Porównaj
ultra 1920x1080
6.5  fps    + Porównaj
» Niegrywalna na większości testowanych laptopów.
low 1024x768
70.3  fps    + Porównaj
med. 1366x768
50.6  fps    + Porównaj
high 1366x768
40.1  fps    + Porównaj
ultra 1920x1080
29.1  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach high.
Anno 2070

Anno 2070

2011
low 1024x768
90.8  fps    + Porównaj
med. 1366x768
40.5  fps    + Porównaj
high 1366x768
25.4  fps    + Porównaj
ultra 1920x1080
13.4  fps    + Porównaj
» Na wszystkich testowanych laptopach grywalna przy ustawieniach med..
lowmed.highultraQHD4K
GRID 210152.335.618.9
Metro: Last Light52.33628.619.3
Tomb Raider59.933.622.112.5
Crysis 328.515.410.36.5
Diablo III70.350.640.129.1
Anno 207090.840.525.413.4
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
1
2
3
1
5

4
2

6








Więcej informacji w rankingu płynności w grach
